KNOWING YOUR SEWING MACHINE —————————————————————————————————————————————
38
MAINTENANCE
Changing the Light Bulb
1
Remove the power supply plug from the
outlet.
2
Loosen the face plate screw.
3
Remove the face plate from the machine as
shown below.
Note
● Use only a bulb of the same type and rated
15 W.
4
Replace the sewing light bulb.
1 Bulb
2 Loosen
3 Tighten
5
Reattach the face plate and fasten the screw.
Oiling
1
Remove the power supply plug from the
outlet.
2
Remove the needle plate and the face plate,
and then put 2 to 3 drops of oil at each point
indicated by the arrows.
3
Operate the machine at a fast speed for a
short time without thread installed.
4
Be sure to wipe any excess oil off the
machine.
1
3
2
