- 7 -
(3)-1 FEED UNIT (New type)
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XF7691001 BASE PLATE ASSY 1000039425 45 XC3183051 FELT
2 XE2995001 HORIZONTAL FEED SHAFT 46 XA0286051 WIRE CLIP 1000042697
3 014400432 SET SCREW SOCKET (CP) M4X4 47 060400516 SCREW BIND M4X5
4 060301206 SCREW BIND M3X12 48 XD1856100 PILE H 1000055798
5 XF3569001 OUTER ROTARY HOOK ASSY H 1000047756 49 XE6472001 NEEDLE PLATE HOLDER 1000039425
6 XE1480001 OUTER ROTARY HOOK SHAFT
7 137805022 SPACER 50 XF7720001 FEED UNIT SUPPLY ASSY C-EMB N 1000039425
8 137976021 WASHER 6
9 XZ5092001 SHAFT SUPPORTER 1000039425
10 0A4400806 SCREW,PAN(S/P WASHER)M4X8 1000039425
11 014400632 SET SCREW SOCKET (CP) M4X6
12 XE3650101 INNER ROTARY HOOK BRACKET ASSY H 1000016400
13 XE2998001 PHOTO DIODE SUPPORTER
14 XE2999001 PHOTO DIODE HOLDER ASSY
15 XC7866351 CORD HOLDER 1000012334
16 060260316 SCREW BIND M2.6X3
17 000020416 SCREW BIND M2X4 1000016096
18 0A5300806 SCREW PAN (S/P WASHER) M3X8
19 XE5360001 LOWER SHAFT ASSY
20 XC4943021 TIMING PULLEY D
21 014500532 SET SCREW SOCKET (CP) M5X5
22 X52664020 LOWER SHAFT BUSHING
23 X51383020 WASHER,THRUST
24 048060343 RETAINING RING E6 1000038911
25 XC8798021 SET COLLAR
26 XC4944021 BUSHING PRESSER B
27 085310615 TAPTITE BIND B M3X6
28 XF7693001 NEEDLE PLATE A ASSY H 1000039425
29 XF7694001 NEEDLE PLATE A 1000039425
30 XF2440001 STOPPER PLATE 1000030484
31 XE1488001 NEEDLE PLATE B SUPPORT PLATE
32 XF7695001 F GEAR STOPPER PLATE 1000039425
33 060260316 SCREW BIND M2.6X3 1000039425
34 XE6473001 SCREW NEEDLE PLATE H 1000039425
35 XE3004001 LEAD WIRE GUIDE HOLDER
36 060300416 SCREW BIND M3X4
37 XF5447001 THREAD CUTTER MODULE SUPPORTER 1000039425
38 060400516 SCREW BIND M4X5 1000039425
39 132421021 BUSHING PRESSER
40 X57908021 TAPTITE,BIND S M4X10
41 XD1855551 INNER ROTARY HOOK ASSY R/H 1000055798
42 X52800120 BOBBIN
43 XE1489001 STUD SCREW M4
44 060301206 SCREW BIND M3X12
