CONTENTS
(1) MAIN FRAME / COVER ························································ 2
(2) UPPER SHAFT / NEEDLE BAR / PRESSER FOOT UNIT ············· 4
(3)-1 FEED UNIT (New type) ························································ 6
(3)-2 FEED UNIT (Old type) ·························································· 8
(4) THREAD CUTTING UNIT ····················································· 10
(5) BOBBIN WINDING / NEEDLE THREADING MECHANISM ········· 12
(6) ELECTRIC PARTS / MAIN MOTOR UNIT ······························· 14
(7) EMBROIDERY UNIT ··························································· 16
(8) ACCESSORY PARTS / USER MANUAL / PACKAGE ··············· 18
SPARE PARTS ·································································· 20
Note on parts:
We keep performance parts for this sewing machine for at least 8 years after this model is discontinued.
Performance parts are the necessary parts to maintain the function of the sewing machine.
