- 9 -
(3)-2 FEED UNIT (Old type)
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XE5359001 BASE PLATE ASSY 45 X52800120 BOBBIN
2 XC8782021 NEEDLE PLATE SUPPORTER SHAFT B 46 XE1489001 STUD SCREW M4
3 021300106 NUT 1 M3 47 060301206 SCREW BIND M3X12
4 XE2994001 THREAD CUTTER MODULE SUPPORTER 48 XC3183051 FELT
5 XE2995001 HORIZONTAL FEED SHAFT 49 XA0286051 WIRE CLIP 1000042697
6 014400432 SET SCREW SOCKET (CP) M4X4 50 060400516 SCREW BIND M4X5
7 060301206 SCREW BIND M3X12 51 XD1856000 PILE H 1000019976
8 XC2210021 OUTER ROTARY HOOK ASSY H 1000023473
9 XE1480001 OUTER ROTARY HOOK SHAFT 52 XE5555101 FEED UNIT SUPPLY ASSY C-EMB 1000029406
10 137805022 SPACER
11 137976021 WASHER 6
12 XE1481001 SHAFT SUPPORTER
13 138172021 SCREW,PAN(S/P WASHER)M4X10
14 014400632 SET SCREW SOCKET (CP) M4X6
15 XE3650101 INNER ROTARY HOOK BRACKET ASSY H 1000016400
16 XE2998001 PHOTO DIODE SUPPORTER
17 XE2999001 PHOTO DIODE HOLDER ASSY
18 XC7866351 CORD HOLDER 1000012334
19 060260316 SCREW BIND M2.6X3
20 000020416 SCREW BIND M2X4 1000016096
21 0A5300806 SCREW PAN (S/P WASHER) M3X8
22 XE5360001 LOWER SHAFT ASSY
23 XC4943021 TIMING PULLEY D
24 014500532 SET SCREW SOCKET (CP) M5X5
25 X52664020 LOWER SHAFT BUSHING
26 X51383020 WASHER,THRUST
27 048060343 RETAINING RING E6 1000038911
28 XC8798021 SET COLLAR
29 XC4944021 BUSHING PRESSER B
30 085310615 TAPTITE BIND B M3X6
31 XE5361201 NEEDLE PLATE A ASSY H 1000029406
32 XE5362001 NEEDLE PLATE A
33 XF2440001 STOPPER PLATE 1000030484
34 XE1488001 NEEDLE PLATE B SUPPORT PLATE
35 XD1623251 F GEAR STOPPER PLATE 1000025374
36 060260316 SCREW BIND M2.6X3
37 X50487021 SCREW M4 H
38 XE3004001 LEAD WIRE GUIDE HOLDER
39 060300416 SCREW BIND M3X4
40 XE3005001 THREAD CUTTER MODULE SUPPORTER
41 060400516 SCREW BIND M4X5
42 132421021 BUSHING PRESSER
43 X57908021 TAPTITE,BIND S M4X10
44 XD1855451 INNER ROTARY HOOK ASSY R/H 1000053475
