- 11 -
(4) THREAD CUTTING UNIT
No. CODE NAME R/H REMARKS
1 XC9733051 THREAD CUTTER FRAME ASSY
2 XC9735050 SPACER
3 XG2930001 CUTTER BLADE ASSY H 1000056778
4 XE4994001 PRESSER PLATE ASSY H
5 060300516 SCREW BIND M3X5
6 XC2598120 SPRING PLATE H
7 XC2587020 RUBBER
8 048030343 RETAINING RING E3 1000038911
9 XC2583121 THREAD HOOK ASSY
10 137713020 POLYESTER SLIDER
11 X56731020 WASHER
12 048040343 RETAINING RING E4 1000038911
13 XC9736050 CUTTER HOLDER
14 XC2581221 THREAD CUTTER LEVER
15 XC2582020 THREAD CUTTER LEVER GEAR
16 0A4300605 SCREW PAN (S/P WASHER) M3X6
17 XC2588321 MOTOR HOLDER ASSY 1000018482
18 XC2592020 IDLE GEAR A
19 XC2593020 IDLE GEAR B
20 X56323021 SPRING
21 048020343 RETAINING RING E2 1000038911
22 XF7723001 C PULSE MOTOR SMJ35-4840-BP 1000040101
23 060300416 SCREW BIND M3X4
24 XC2594121 COLLAR
25 060402016 SCREW BIND M4X20
26 X53169020 BAND
27 137713020 POLYESTER SLIDER
28 XC8407020 WAVE-SHAPE SPRING WASHER
29 XE3186001 PHOTO TRANSISTOR ASSY
30 XC9199051 SENSOR HOLDER
31 0A4300605 SCREW PAN (S/P WASHER) M3X6
32 060400516 SCREW BIND M4X5
33 060300516 SCREW BIND M3X5
34 X53169020 BAND
35 XD0075351 THREAD CUTTER SUPPLY ASSY 1000044631
