- 13 -
(5) BOBBIN WINDING / NEEDLE THREADING MECHANISM
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
BOBBIN WINDING MECHANISM NEEDLE THREADING MECHANISM
1 XE3008001 BOBBIN WINDER ASSEMBLY HOLDER 16 XE3011101 THREAD GUARD ASSEMBLY 1000055651
2 XE1495001 BW SHAFT HOLDER ASSEMBLY 17 XA9935050 SPRING TAPE
3 X55238021 RUBBER RING 18 XA0083121 TENSION DISC A H
4 XZ5039001 BOBBIN WINDER SHAFT SPRING 19 XA0084121 TENSION DISC B H
5 048050343 RETAINING RING E5 1000038911 20 XD0573021 WASHER
6 XA2862021 BOBBIN WINDER SHAFT STOPPER 21 XA1388021 TENSION DISC WASHER
7 XZ0070021 BOBBIN WINDER SPRING 22 XE1506001 THREAD RELEASE PLATE
8 XC2614051 SW ADJUST PLATE 1000046449 23 XE3014001 SPRING
9 060300616 SCREW BIND M3X6 24 XE3015001 THREAD TENSION ADJUSTING SCREW
10 XC2612051 SW ASSY:BW-F 25 XE3016001 THREAD TENSION PLATE ASSY
11 XC4672051 BOBBIN BASE ASSY H 26 XE3019001 ADJUSTING SCREW SPRING PLATE
12 XC2616051 BOBBIN BASE 1000034911 27 XE3020101 THREAD TENSION ADJUSTING GEAR 1000033516
13 XA5877021 BOBBIN THREAD CUTTER HOLDER 28 XE3201001 THREAD TENSION DIAL
14 X80321021 NT LOWER THREAD CUTTER H 29 XC9234021 TENSION DIAL SHAFT
15 X57908021 TAPTITE,BIND S M4X10 30 X56839021 NOTCHED SPRING 1000043008
31 062300416 SCREW PAN M3X4
32 XC6957121 THREAD TAKE UP SPRING H
33 XD0377151 THREAD CATCHING SPRING CASE FE H
34 XE5731001 THREAD CUTTING SHUTTER H
35 0A4301806 SCREW, PAN (S/P WASHE) M3X18
36 XE3021001 THREAD SENSOR HOLDER
37 XE3022001 UPTHREAD PCB ASSY CCOM
38 XD0383050 THREAD GUIDE WIRE FE H
39 XA9996051 WASHER,PLAIN
40 XC7564021 SCREW, PAN(S/P WASHER)M3X6
41 XE3025001 PLATE ASSEMBLY
42 060300416 SCREW BIND M3X4
43 XE3028001 THREAD GUARD HOLDER S
44 060300416 SCREW BIND M3X4
45 XE1519101 BOBBIN WINDER GUIDE ASSY
46 XC3037021 SCREW3X10
47 XE3029001 THREAD GUARD COVER H
48 XE1489001 STUD SCREW M4
