Brother PE430 - Page 18

- 15 -
(6) ELECTRIC PARTS / MAIN MOTOR UNIT
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
ELECTRIC PARTS MAIN MOTOR UNIT
1 XE5478201 MAIN PCB SUPPLY ASSY-B R 1000054748 24 XE3180101 MAIN MOTOR SUB ASSY:CCOM V (USA) H 1000056719
2 XE3032001 LCD SUPPORTER XG8099001 MAIN MOTOR SUB ASSY:CCOM-2-V0 H 1000056719
3 XE3033001 LIGHT PLATE ASSY (OTHER)
4 XC2435020 ZIGZAG ADJUSTING NUT 25 XC3803120 MOTOR FAN H 1000033777
5 018301232 BOLT SOCKET M3X12 26 XE3046001 MOTOR HOLDER
6 XD0830151 LCD SUPPLY ASSY (~F1G******) R 1000028578 27 0A5300806 SCREW PAN (S/P WASHER) M3X8
XF2349001 LCD SUPPLY ASSY (G1G******~) R 1000028578 28 XA8474021 UPSET 4X12 DB
7 XE5363003 TOUCH PANEL ASSY (HE1) R 1000026162 29 XC2685051 T BELT494-2GT-6 H
XE5363004 TOUCH PANEL ASSY (PE500) R 1000028353
XE5363001 TOUCH PANEL ASSY (OTHER) R
8 XE3267001 INLET ASSY:CCOM (120V)
XE4205001 INLET ASSY:CCOM EU (230V)
XE3183001 INLET ASSY:CCOM UL (HE1, PE500) 1000026162
9 XE3654001 POWER PCB SUPPLY ASSY 120:CCOM R
(120V)
XE4293001 POWER PCB SUPPLY ASSY 230:CCOM
(230V)
10 XE3039101 INSULATION COVER
11 XE3040101 INSULATION PLATE 1000017054
12 XE3041001 POWER LEAD WIRE ASSY:CCOM
13 085311016 TAPTITE BIND B M3X10 1000024772
14 XE3042001 CARD CONNECT COVER
15 060400516 SCREW BIND M4X5
16 XA0286021 WIRE CLIP
17 XE3043001 CORD GUIDE
18 XE3044001 CORD GUIDE A
19 060400816 SCREW BIND M4X8
20 XE3318001 INSULATE SHEET CCOM BACK
21 XE3045001 SUPPORTER MAIN PWB
22 X53169020 BAND
23 XC6052121 POWER SUPPLY CORD:UL CSA-LF H 1000048404
(USA)
XD0111151 POWER SUPPLY CORD:IRAM (ARG) H
XF0749001 POWER SUPPLY CORD:BRZ (BRA120V) H 1000025696
XE4301001 POWER SUPPLY CORD:BRZ 220V (BRA220V) H
X59354221 POWER SUPPLY CORD BS (UK&IRE) H 1000035202
XA0070121 POWER SUPPLY CORD (OTHER) H
