- 17 -
(7) EMBROIDERY UNIT
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XC3807121 MAIN FRAME ASSEMBLY 1000056645 45 X59853020 RUBBER CUSHION
2 XC4153020 X GEAR 46 XA1899021 SPRING
3 048030343 RETAINING RING E3 1000038911 47 XC3824121 HANDLE
4 XC4154020 X DRIVING GEAR 48 XA5352020 CORD PRESSER
5 X53330020 WASHER 49 XA6281020 Y PRESSER PLATE
6 X58715021 T BELT 40S2M400 H 50 XA6334020 SHUTTER PRESSER PLATE
7 048060343 RETAINING RING E6 1000038911 51 XA6152021 ROLLER ASSY
8 XA5308021 X TENSION PULLEY ASSY 52 XC5001021 LEAD WIRE ASSY, YPM
9 XC3809021 X CARRIAGE GUIDE PLATE ASSY 53 X53169020 BAND
10 XA5314020 CORD GUIDE 54 X52318021 COACHING CLIP CS-2
11 XC3811021 MOTOR,PULSE:Y SMJ35-4823-C 55 085300815 TAPTITE BIND P M3X8
12 XC7564021 SCREW, PAN (S/P WASHER) M3X6 56 XE7628101 EMBROIDERY SUPPLY ASSY EU 1000025686
13 XA5316021 X GUIDE SHAFT XE7511001 EMBROIDERY SUPPLY ASSY (OTHER) 1000016800
14 XA5317120 X SLIDER
15 XA5318120 X BELT PRESSER
16 0A4400806 SCREW PAN (S/P WASHER) M4X8
17 XC5350020 X SHUTTER
18 XE3182101 LEAD WIRE ASSY:EMB UNIT 1000056640
19 085301616 TAPTITE BIND P M3X16
20 XE3176001 XSENS PCB ASSY:CCOM
21 000020416 SCREW BIND M2X4 1000016096
22 XC3815021 MOTOR,PULSE:X SMJ40-4888-A
23 0A4300506 SCREW, PAN (S/P WASHER) M3X5
24 XA5324221 X CARRIAGE ASSY
25 XC4155020 Y GEAR
26 048020343 RETAINING RING E2 1000038911
27 XC4156120 Y DRIVING GEAR
28 XA5330021 T BELT 40S2M316 H
29 XA6151021 Y TENSION PULLEY ASSY
30 XA5338121 Y CARRIAGE 1000022851
31 XC5287121 NOTCHED SPRING
32 XA5340121 Y GUIDE SHAFT
33 103810022 WASHER, WAVE SPRING
34 048040343 RETAINING RING E4 1000038911
35 XA5341120 Y SHUTTER 1000017052
36 XA5342120 Y SLIDER
37 XA8390021 SCREW
38 XE3178001 YSENS PCB ASSY:CCOM
39 XA5346020 CORD HOLDER
40 060300416 SCREW BIND M3X4
41 087411416 TAPTITE CUP B M4X14
42 XC2133025 CARRIAGE COVER R
43 XE3398001 ES COVER U R
44 XE3052001 ES COVER D R
