(1) MAIN FRAME / COVER
No. CODE NAME R/H REMARKS No. CODE NAME R/H REMARKS
1 XE5481001 REAR COVER SUB ASSY R 36 XC0508020 RUBBER WASHER
2 XC4517151 BOBBIN PRESSER 1000018473 37 085311016 TAPTITE BIND B M3X10
3 0A4302006 SCREW PAN (S/P WASHER) M3X20 38 XE2941001 BASE PLATE
4 021300106 NUT 1 M3 39 XA1805021 BASE RUBBER A H
5 XA1786053 SPOOL PIN 40 XC3471021 ADJUSTING SCREW
6 XE1394001 SPOOL PIN HOLDER ASSY 41 XC3472021 BASE PLATE RUBBER H
7 XE1490101 THREAD GUIDE SUPPORTING PLATE 42 XD0351051 LEAD WIRE ASSY MAIN BODY FCOMB
8 085311216 TAPTITE BIND B M3X12 43 XE1829001 FERRITE CORE:K1NF-75(N)BK2
9 XE2910001 THREAD GUIDE PLATE ASSY 44 XE2942001 CONNECTOR HOLDER
10 XE2911001 THREAD GUIDE PLATE 45 XD0353051 ES PIN F-A
11 XE2912001 SHAFT 46 XD0945051 ES PIN F-B
12 XE2913001 THREAD GUIDE SPRING 47 XD0967051 SPRING,COMPRESSION
13 X57605051 SPRING 48 XC2514021 FEED BAR SPACER
14 048020343 RETAINING RING E2 1000038911 49 048020343 RETAINING RING E2 1000038911
15 X59642021 SCREW 50 060300516 SCREW BIND M3X5
16 XE5552001 FRONT COVER SUPPLY ASSY:PE430 R 51 XE3145001 CONNECTOR HOLDER COVER
(PE430) 52 X57908021 TAPTITE,BIND S M4X10
XE5553001 FRONT COVER SUPPLY ASSY:NV90E R 53 XD0354251 NEEDLE PLATE B ASSY
(NV90E) 54 XD0355251 NEEDLE PLATE B H
XF1263001 FRONT COVER SUPPLY ASSY:HE1 R 1000026162 55 XC7371022 SLIDE BUTTON
(HE1) 56 XD1666052 CUTTER COVER
XF2297001 FRONT COVER SUPPLY ASSY:PE500 R 1000028353 57 XD1461051 NEEDLE PLATE COVER SPRING
(PE500) 58 X80321021 NT LOWER THREAD CUTTER H
XG1089001 FRONT COVER SUPPLY ASSY:PE525 R 1000028353 59 XD1645021 NEEDLE PLATE COVER SUPPLY ASSY H
(PE525) 60 XE1447201 HANDLE 1000029226
17 XE3096101 SS BUTTON 1000019614 61 XE2953001 HANDLE HOLDER
18 XE2929001 NP BUTTON 62 XE1449001 HANDLE SHAFT
19 XE5274001 SSVR PCB ASSY:CEMB 63 048040343 RETAINING RING E4 1000038911
20 XE2935001 INSULATOR SHEET:CCOM SS 64 137713020 POLYESTER SLIDER
21 XC3751021 MINI CLAMP:UAMS-02 65 XE2954001 BASE FOOT COVER
22 085311016 TAPTITE BIND B M3X10 66 XE5354001 BOTTOM COVER
23 XC6363021 BOARD PRESSER 67 060400816 SCREW BIND M4X8
24 XE2367001 LED LAMP RIGHT SUPPLY ASSY LE1 68 XE2956001 STUD
25 XE3376001 RUBBER 69 087411416 TAPTITE CUP B M4X14
26 XE2937001 FACE PLATE ASSY R 70 085301616 TAPTITE BIND P M3X16
27 X80321021 NT LOWER THREAD CUTTER H 71 XC7568051 SCREW, PAN(S/P WASHER)M4X14
28 XE1435001 FACE PLATE CUTTER HOLDER
29 138433021 TAPTITE,PAN B M3X6
30 XC9604051 NEEDLE THREAD LEVER KNOB
31 XA5825051 NEEDLE THREAD LEVER SHAFT
32 XC3039151 NEEDLE THREAD LEVER
33 138260051 THREAD THROUGH LEVER SPRING
34 XA6320050 SHAFT PRESSER PLATE
35 XA5525051 WASHER,PLAIN
