Brother XL-2121 User Manual

45
5
Gathering
1
Set the Pattern Selection Dial to Straight
Stitch.
2
Loosen the tension of the upper thread so that
the lower thread lies on the underside of the
material.
3
Sew a single row (or many rows) of Straight
Stitches.
4
Pull the lower threads to gather the material.
Darning
1
Remove the power supply plug from the
outlet. Put the darning plate on the needle
plate. Connect the power supply plug into the
wall outlet.
2
Set the Pattern Selection Dial to Straight
Stitch.
3
Put the section you want to darn under the
presser foot, together with a fabric for
reinforcement.
4
Lower the presser foot.
5
Begin sewing by alternating between gently
drawing the work away from you and pulling
it toward you.
Stitch Name Pattern
Stitch
Length
[mm (inch.)]
Straight Stitch
(Center Needle Position)
2.5 (3/32)
Straight Stitch
(Center Needle Position)
4.0 (3/16)
Straight Stitch
(Left Needle Position)
2.5 (3/32)
Stitch
Name
Pattern
Stitch
Length
[mm (inch.)]
Foot Other
Straight
Stitch
(Center
Needle
Position)
2.5 (3/32)
Zigzag
Presser
Foot
Darning
Plate
Straight
Stitch
(Center
Needle
Position)
4.0 (3/16)
Straight
Stitch
(Left
Needle
Position)
2.5 (3/32)

Brother XL-2121 Specifications

General

Type	Mechanical
Operation	Manual
Buttonhole Styles	4-Step
Needle Threading	Manual
Free Arm	Yes
Bobbin Type	Drop-in
Bobbin	Class 15
Sewing Speed	800 stitches per minute
Stitch Length	Up to 4 mm
Stitch Width	Up to 5 mm
