Broyhill A101017510 - Step 1: Post and Base Cover Assembly; Post and Base Cover Assembly

Assembled View:
Put the Base Cover (C) on the Post1/2/3 (A/
B/AC), clip the Post Cover (D) into the Post
1/2/3(A/B/AC), using the Bolt (H1) to connect
and lock the Post Cover (D) and the Post
1/2/3(A/B/AC), tighten by Wrench (HW).
STEP 1
8/27
