Assembled View:
5X
1X
4X
4X
1X
Secure small roof inclined beam cover
plate (U) to small top skew beam (I) using
bolt (BB) and flat washer (CC), then secure
small top cover (R) to small top connector
(K) using bolt (AA) and flat washer (CC),
tighten with wrench (Z1).
