Assembled View:
4X
4X
8X
8X
8X
Secure big top and large cover (T5/T6) to
the big roof top beam (O1/O2) using bolt
(BB) ,rubber washer(MM) and flat
washer (CC), tighten with wrench (Z1).
67(3
27/31
