Product Information
150, 175, 200 Models
Displacement 158.2 cu. in. (2592 cc)
Engine Type 60° V, 6 Cylinder, Two-Cycle, E-TEC
Full Throttle Operating
Range
150 HP – 4850 to 5850 RPM
175 HP – 4850 to 5850 RPM
200 HP – 4850 to 5850 RPM
Power
(1)
150 HP – 150 HP (110 kw) @ 5350 RPM
175 HP – 175 HP (129 kw) @ 5350 RPM
200 HP – 200 HP (147 kw) @ 5350 RPM
Idle RPM in Neutral
(2)
500 ± 50
Ignition Timing
(2)
Controlled by the outboard’s EMM
Emission Control System:
per SAE J1930
(2)
ECM, E-TEC (Engine Control Module, E-TEC)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON) – Refer to Minimum Octane
on page 18
Oil – Lubricant Evinrude/Johnson XD100 oil or TC-W3 NMMA-certified oil
– Refer to Oil Requirements on page 16
Warning Signals Controlled by the outboard’s EMM
Battery, Minimum
(3)(4)
675 CCA (845 MCA) 12 volt or
800 CCA (1000 MCA) 12 volt below 32°F (0°C)
Spark Plug
(2)
Refer to ECI Label
Fuses P/N 967545 – Refer to Fuse on page 31
Fuel Filter P/N 502906
Battery Charging 50-Amp, Fully Regulated, Dual Isolated
Gearcase – Lubricant
(5)
– Capacity
Evinrude/Johnson HPF XR Gearcase Lubricant
DPL, DSL Models (O) – 33.1 fl. oz. (980 ml)
DHL, HSL Models (L2) – 32.5 fl. oz. (960 ml)
DPX, DBX, DMX Models (M2) – 38.9 fl. oz. (1150 ml)
DCX Models (M2-CR) – 35.8 fl. oz. (1060 ml)
Power Trim/Tilt – Fluid
– Capacity
Evinrude/Johnson Power Trim/Tilt and Power Steering Fluid
21 fl. oz. (622 ml)
Propeller Refer to Propeller Selection on page 49
Weight L Models – 418 lbs. (190 kg)
X Models – 433 lbs. (196 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
79.0 dB(A)
Transom Height L Models – 19 1/2 to 20 in. (495 to 508 mm)
X Models – 24 1/2 to 25 in. (622 to 635 mm)
