BRP ROTAX 916 i A Series Maintenance Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
NOTICE
For longer flights replenish oil to max. mark to warrant more oil reserve.
NOTICE
Only use brand name oil in accordance with the latest Operators Manual (OM)
and the latest Service Instruction “Selection of suitable operating fluids“ of the
respective engine type.
Step
Procedure
7 Replenish oil as required.
8
Check oil level - Marks on the oil dipstick.
9 Fit the oil dipstick and tighten the oil tank cover (1) by hand.
Figure 6.4: Oil level check/Replenish
1
Oil tank cover, without venting
2
Oil dipstick
12–10–00
Page 8
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1

BRP ROTAX 916 i A Series Specifications

General

Brand	BRP
Model	ROTAX 916 i A Series
Category	Engine
Language	English
