MAINTENANCE MANUAL LINE
PURGING THE OIL SYSTEM
General note
NOTICE
Purging of the oil system is extremely important for operation and service life of
the engine and therefore the procedure must be followed meticulously.
See current Installation Manual (IM) for the engine type 916 i A Series,
Chapter 79-00-00 section Purging the lubrication system and latest ver-
sion of SI-916 i-003.
Purging the oil
system
Purging the oil system is necessary:
• with initial installation of new engine
• after reinstallation (e.g. after overhaul)
• after maintenance work during which the lubrication system was opened and voided (e.
g. removal of the oil tank or oil cooler, replacement of oil lines).
FLUSHING THE OIL CIRCUIT
General note
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded! Disconnect negative terminal of battery.
Oil tank Clean the oil tank.
Temporary oil
lines
Temporary oil lines (only for flushing) must be fitted so that the oil radiator is not con-
nected. The return line is routed into a separate, clean receptacle and not back to the oil
tank.
NOTE
This is done to prevent metal chips and other debris from entering the radiator or
oil tank.
Filling Fill the oil tank with approx. 3 l (0.8 gal (US)) of engine oil.
Procedure The following steps have to be carried out after refilling:
12–20–00
Page 38
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
