MAINTENANCE MANUAL LINE
CHECK OF WIRING
General note
m WARNING
Risk of electric shock!
Ignition “OFF” and system grounded! Disconnect negative terminal of battery.
m WARNING
Risk of burns and scalds. Hot engine parts.
Always allow engine to cool down to ambient temperature before starting work.
Procedure The following steps have to be carried out:
Step
Procedure
1 Inspect all cable connectors and their connections for tight fit, good contact,
corrosion or damage and replace as necessary.
2
Inspect all ground connections for corrosion and damage, replace if
necessary.
3
Inspect plug connections of ignition coils for corrosion or damage and re-
place if necessary.
4
Verify plug connections on generator cables with rectifier-regulator and con-
nections of all cables on regulators for good contact, tight fit, corrosion, dis-
coloration or damage and replace if necessary.
5
Inspect grounding cables for tight fit, corrosion or damage and replace if
necessary.
6
Verify shielding of cable assemblies for corrosion or damage, good ground
contact and tight fit, inspect the attachment of the shielding and replace if
necessary.
7
Inspect all 8 ignition cables to spark plug connector for corrosion or damage
and tight fit and replace if necessary.
8
Fuse unit: Check fuse plugs/relays and replace if necessary.
9 ECU: Check the condition of the connectors or if any pins are bent or
pushed in.
12–20–00
Page 44
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
