BRP-Rotax
MAINTENANCE MANUAL LINE
Figure 7.26: Oil tank
1
1-ear clamp 10.3-12.8 mm
2
Control hose 600 mm (23.6 inch.)
3
Hose nipple
12–20–00
Page 54
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
