BRP ROTAX 916 i A Series Maintenance Manual

BRP-Rotax
MAINTENANCE MANUAL LINE
Figure 5.13
1
Hex./Torx-flange screw M8x45
2
Hex./Torx-flange screw M6x40
Figure 5.14: Screw diagram
Step
Procedure
12 Inspect the propeller flange run-out. See also Chapter 72-10-00 section
Wear limits. (GB18).
13
Lock the crankshaft into place according to Chapter 12-20–00 section
"Locking/Loosen of the crankshaft''
14 Secure Hex. screw M12 x 20 with LOCTITE 243.
Tightening torque 20 Nm (15 ft. lb.).
05–50–00
Page 16
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
