MODELS 2000XP / 2100SP CONTROLS
MODEL 2100SP RADIO CONTROL
OPERATING PROCEDURES
1. Lift Down / Up:
To lower the cutter wheel, push the switch away from the operator. To lift the cutter wheel, pull the switch
towards the operator. The cutter wheel lift is stationary when the switch is in the center location.
2. Tongue Out / In:
To extend the tongue out, push the switch away from the operator. To retract the tongue in, pull the switch
towards the operator. The tongue is stationary when the switch is in the center location.
3. Swing Left / Right:
With the tether control or a LOR transmitter, to swing the cutter wheel to the left, push the switch, away
from the operator. To swing the cutter wheel to the right, pull the switch, towards the operator. The swing is
stationary when the switch is in the center location.
With an Omnex transmitter, to swing the cutter wheel to the right, push the switch, away from the operator. To
swing the cutter wheel to the left, pull the switch, towards the operator. The swing is stationary when the switch
is in the center location.
4. Drive Forward / Reverse:
To move the machine forward, push the switch away from the operator. To reverse the machine, pull the switch
towards the operator. The machine is stationary when the switch is in the center location.
5. Drive High / Low:
High and low are used to move and position the machine. Low is used to position the machine near the
stump or while cutting the stump. High is used to move the machine to the working area. Handle must be down
to use the high speed travel.
6. Engine Stop Switch:
Shuts off the power to the engine and to the hydraulic valve. The engine stop switch must be pulled out or in
the run position for the engine to start.
7. Steer Right / Left:
With the tether control or a LOR transmitter, to steer the machine to the left, push the switch, away from the
operator. To steer the machine to the right, pull the switch, towards the operator. The steering is stationary
when the switch is in the center location.
With an Omnex transmitter, to steer the machine to the right, push the switch, away from the operator. To
steer the machine to the left, pull the switch, towards the operator. The steering is stationary when the switch
is in the center location.
8. Cutter Bump Adjustment:
Turn the knob clockwise to increase the distance the cutter wheel drops when you activate the cutter wheel
lift control and counter-clockwise to decrease the cutter wheel drops.
9. Power:
A red light in the center of the button indicates power.
10. Batteries (not shown):
Omnex transmitters require (4) AA batteries (if the batteries are dead, the engine will shut down).
LOR transmitters require (2) D batteries (if the batteries are dead, the engine will shut down).
