Brush Bandit 2000XP - Cutterwheel Components

Bandit
Copyright 5/09 PAGE 77
MODELS 2000XP / 2100SP CUTTER WHEEL COMPONENTS
NOTICE Nuts, bolts, washers, and all other components can be ordered by physical description.
MODEL 2000XP MODEL 2100SP
LOCATION PART NUMBER PART NUMBER DESCRIPTION
1 a. 900-4900-13 900-4900-13 3/8”-16NC x 1” Hex Head Bolt
b. 900-4906-62 900-4906-62 3/8” Lock Washer (Not Shown)
2. 900-4913-27 900-4913-27 3/8” x 1 3/4” O.D. Washer
3. 900-4906-76 900-4906-76 1/2”-13NC x 2 1/2” Hex head Bolt
4. 900-1914-15 900-1914-15 Cutter Wheel Bearing
5 a. 900-4906-84 900-4906-84 1/2” -13NC Automation Lock Nut
b. 900-4909-18 900-4909-18 1/2” Mill Carb Washer
6. 991-3000-50 993-300005 Cutter Wheel Spacer
7. 900-4903-17 900-4903-17 1/2”-13NC x 2 1/2” Hex Head Bolt (Full Thread)
8. 993-300002 993-300002 Bolt-On Hub
9 a. 991-3000-19 993-300880 Cutter Wheel - 18 Tooth (Start 6/08)
b. N/A 993-300001 Cutter Wheel - 20 Tooth (Pre 6/08)
10 a. 900-4906-84 900-4906-84 1/2” -13NC Automation Lock Nut
b. 900-4909-18 900-4909-18 1/2” Mill Carb Washer
11. 993-300003 993-300003 Cutter Wheel Shaft
12. 993-300007 993-300007 3/8” Key x 2”
13. 993-300006 993-300006 3/8” Key x 2 3/4”
14. 900-1903-36 900-1903-36 Bushing For Bolt-On Hub
15. 991-3000-50 993-300004 Cutter Wheel Spacer
16 a. 900-1915-63 900-1913-71 Sheave For V-Belt Drive (Start 12/07)
b. N/A 900-1910-91 Sprocket For Poly Chain Belt Drive (Pre 12/07)
17 a. 900-1915-64 900-1913-72 Bushing For V-Belt Drive (Start 12/07)
b. N/A 900-1908-15 Bushing For Poly Chain Belt Drive (Pre 12/07)
18. 900-9907-76 900-9907-76 Green Tooth With Nut (Start 6/08)
19. 900--9907-42 900-9907-14 Pocket Bolt For Green Teeth (Start 6/08)
20. 900-9907-05 900-9907-05 Straight Pocket For Green Teeth (Start 6/08)
21. 900-9907-04 900-9907-04 Angle Pocket For Green Teeth (Start 6/08)
22. N/A 900-9903-75 Straight Pin Tooth (Pre 6/08)
23. N/A 900-9903-76 Left Pin Tooth 45° (Pre 6/08)
24. N/A 900-9903-77 Right Pin Tooth 45° (Pre 6/08)
25. N/A 900-9903-79 Threaded Pocket For Pin Teeth (Pre 6/08)
26. N/A 900-9903-78 Counter Bored Pocket For Pin Teeth (Pre 6/08)
27. N/A 900-9903-96 Tooth Bolt For Pin Teeth (Pre 6/08)
28 a. 900-9907-77 900-9907-15 18 Green Teeth Kit - Includes Pockets & Bolts (Start 6/08)
b. N/A 900-9903-87 20 Pin Teeth Kit - Including Pockets & Bolts (Pre 6/08)
29. 900-9904-57 900-9904-57 1/2” Allen Key Socket For 1/2” Drive (Not Shown)
