REV061316
YTL-015-691
22 Ton Log Splitter
Brute is a trademark of Briggs & Stratton Power Products Group, LLC and is
used under license.
\
Instruction & Assembly
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

Table of Contents

Questions and Answers

  • A
    Ashley LewisAug 2, 2025
    Why is my Brute YTL-015-691 Log Splitter cylinder rod speed so slow?
    • Y
      yangdanielAug 2, 2025
      The slow cylinder rod speed when extending or retracting in your Brute Log Splitter might be due to several reasons: * Insufficient oil to pump. Check the oil level in the reservoir. * Air in the oil. Check the oil level in the reservoir. * Excessive pump inlet vacuum. Inspect the pump inlet hose for any blockages or kinks. * A damaged or leaking control valve. In this case return the control valve for authorized repair. * An internally damaged cylinder. In this case return the cylinder for authorized repair.
  • N
    Nancy PatrickAug 8, 2025
    Why won't my Brute Log Splitter split wood, or splits it extremely slowly?
    • M
      Mrs. Danielle MillerAug 8, 2025
      If your Brute Log Splitter isn't splitting wood or is splitting it very slowly, it could be due to: * Insufficient oil to the pump. Check the oil level in the reservoir. * Air in the oil. Check the oil level in the reservoir. * Excessive pump inlet vacuum. Check the pump inlet hose for blockages or kinks. * A low control valve setting. Adjust the control valve with a pressure gauge. * A leaking control valve or an internally damaged cylinder. In both cases return the valve or cylinder for authorized repair.
  • S
    Stacy MortonAug 14, 2025
    What to do if the engine bogs down during splitting with Brute Log Splitter?
    • L
      Luke ThomasAug 14, 2025
      If the engine bogs down during splitting with your Brute Log Splitter, it could be due to: * A high control valve setting. Adjust the control valve with a pressure gauge. * Engine control out of adjustment. Adjust the idle control nuts.
  • C
    Carla JohnsonAug 20, 2025
    What to do if the cylinder rod will not move in Brute YTL-015-691 Log Splitter?
    • S
      smithzacharyAug 20, 2025
      If the cylinder rod won't move in your Brute Log Splitter, it could be due to: * Insufficient oil to the pump. Check the oil level in the reservoir. * Blocked hydraulic lines or a blocked control valve. Flush and clean the splitter hydraulic system. * A damaged control valve or an internal cylinder leak. In both cases return the valve or cylinder for authorized repair.
  • P
    Phillip HowellAug 27, 2025
    What to do if Brute YTL-015-691 Log Splitter engine stalls under low load condition?
    • M
      Mr. Anthony PhillipsAug 27, 2025
      If your Brute Log Splitter engine stalls under a low load condition, consider the following: * Blocked hydraulic lines or a blocked control valve. Flush and clean the splitter hydraulic system. * Engine control out of adjustment. Adjust the idle control nuts. * Engine is loaded during idle down mode. Use a shorter log length (24” or less) to allow the engine to speed up before contact.
