Bryant 116B - Detailed Cooling Capacities (CONT.); Cooling Indoor Model and Power; Capacity and Furnace Model; Capacity and Power Data

50
DETAILED COOLING CAPACITIES# (CONT.)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Capacity MBtuh
Tota l
System
KW**
Tota l Sens‡ Tota l Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot a l Sens‡ To t a l Sens‡
116BNA048****A Outdoor Section With CN P V*6124A** Indoor Section
1400
72 (22.2) 56.17 28.42 2.67 53.35 27.42 3.12 50.45 26.41 3.57 47.46 25.38 4.03 44.32 24.31 4.51 41.00 23.20 5.02 67 (19.4) 50.88 34.98 2.84 48.38 34.00 3.25 45.79 33.01 3.66 43.11 31.99 4.09 40.30 30.93 4.55 37.32 29.81 5.04
63 (17.2)†† 47.10 33.57 2.95 44.81 32.61 3.33 42.44 31.63 3.72 39.99 30.62 4.13 37.39 29.57 4.57 34.65 28.46 5.05
62 (16.7) 46.38 41.47 2.96 44.21 40.48 3.34 42.02 41.83 3.72 40.01 40.01 4.12 37.89 37.89 4.56 35.59 35.59 5.05 57 (13.9) 45.57 45.57 2.98 43.79 43.79 3.35 41.92 41.92 3.72 39.95 39.95 4.13 37.83 37.83 4.56 35.54 35.54 5.05
1600
72 (22.2) 57.16 29.95 2.70 54.20 28.93 3.16 51.18 27.90 3.62 48.04 26.84 4.09 44.79 25.76 4.58 41.35 24.63 5.10 67 (19.4) 51.83 37.42 2.88 49.20 36.42 3.30 46.50 35.40 3.72 43.71 34.35 4.16 40.79 33.26 4.62 37.73 32.11 5.12
63 (17.2)†† 48.01 35.84 2.99 45.60 34.86 3.39 43.14 33.85 3.78 40.57 32.81 4.20 37.89 31.73 4.64 35.07 30.58 5.13
62 (16.7) 47.62 47.39 3.00 45.65 45.65 3.38 43.62 43.62 3.77 41.49 41.49 4.18 39.20 39.20 4.63 36.74 36.74 5.12 57 (13.9) 47.51 47.51 3.00 45.58 45.58 3.38 43.56 43.56 3.77 41.43 41.43 4.18 39.15 39.15 4.63 36.69 36.69 5.12
1800
72 (22.2) 57.88 31.40 2.74 54.82 30.37 3.21 51.68 29.32 3.68 48.44 28.24 4.15 45.10 27.15 4.64 41.56 26.00 5.17 67 (19.4) 52.53 39.77 2.92 49.82 38.75 3.35 47.03 37.70 3.78 44.15 36.62 4.22 41.17 35.49 4.69 38.05 34.27 5.19
63 (17.2)†† 48.69 38.02 3.04 46.20 37.01 3.44 43.65 35.97 3.85 41.02 34.90 4.27 38.28 33.77 4.71 35.42 32.54 5.20
62 (16.7) 49.20 49.20 3.02 47.12 47.12 3.42 44.96 44.96 3.82 42.68 42.68 4.24 40.26 40.26 4.70 37.65 37.65 5.19 57 (13.9) 49.13 49.13 3.03 47.06 47.06 3.42 44.90 44.90 3.82 42.63 42.63 4.24 40.21 40.21 4.70 37.61 37.61 5.19
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*CNPV*6124A** 1.00 1.00
CAP**4817A** 0.96 1.00 CAP**4821A** 0.97 1.01 CAP**4823A** 0.97 1.01 CAP**4824A** 0.97 1.01 CAP**6021A** 0.98 0.98 CAP**6024A** 0.98 0.98 CAP**6025A** 0.98 0.98
CNPF*4818A** 0.95 0.99
CNPH*4821A** 0.97 1.01 CNPH*6024A** 0.98 0.98 CNPH*6124A** 0.99 0.99
CNPV*4821A** 0.97 1.01 CNPV*4824A** 0.97 1.01 CNPV*6024A** 0.98 0.98
CSPH*4812A** 0.98 1.02 CSPH*6012A** 0.99 0.99
FB4CNF048 0.97 0.97 FB4CNF060 0.99 0.95
FE4AN(B,F)005 0.98 0.94
FE4ANB006 0.99 0.95
FV4BN(B,F)005 0.98 0.94
FV4BNB006 0.99 0.95
FV4CN(B,F)005 0.98 0.94
FV4CNB006 0.99 0.95
FX4CN(B,F)048 0.99 0.95 FX4CN(B,F)060 1.00 0.96 FX4DN(B,F)049 0.99 0.95 FX4DN(B,F)061 1.00 0.96
FY4ANB060 0.99 1.03
FY4ANF048 0.98 1.02
FY5BNB060 0.99 1.03
FY5BNF048 0.98 0.98
CAP**4817A** 0.96 0.96 315(A,J)AV048090
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CAP**4821A** 0.95 0.95 315(A,J)AV048090 CAP**6021A** 0.97 0.93 315(A,J)AV048090
CNPH*4821A** 0.96 0.96 315(A,J)AV048090 CNPH*6024A** 0.97 0.93 315(A,J)AV048090 CNPH*6124A** 0.98 0.94 315(A,J)AV048090
CNPV*4821A** 0.96 0.96 315(A,J)AV048090
CSPH*4812A** 0.97 0.97 315(A,J)AV048090 CSPH*6012A** 0.98 0.94 315(A,J)AV048090
CAP**4821A** 0.96 0.96 315(A,J)AV060110 CAP**4824A** 0.96 0.96 315(A,J)AV060110 CAP**6021A** 0.97 0.93 315(A,J)AV060110 CAP**6024A** 0.97 0.93 315(A,J)AV060110
CNPH*4821A** 0.96 0.96 315(A,J)AV060110 CNPH*6024A** 0.97 0.93 315(A,J)AV060110 CNPH*6124A** 0.98 0.94 315(A,J)AV060110
CNPV*4821A** 0.96 0.96 315(A,J)AV060110 CNPV*4824A** 0.96 0.96 315(A,J)AV060110 CNPV*6024A** 0.97 0.93 315(A,J)AV060110 CNPV*6124A** 0.99 0.95 315(A,J)AV060110
CSPH*4812A** 0.97 0.97 315(A,J)AV060110 CSPH*6012A** 0.98 0.94 315(A,J)AV060110
CAP**4824A** 0.96 0.92 315(A,J)AV066135 CAP**6024A** 0.98 0.94 315(A,J)AV066135
CNPH*4821A** 0.96 0.92 315(A,J)AV066135 CNPH*6024A** 0.98 0.94 315(A,J)AV066135 CNPH*6124A** 0.98 0.94 315(A,J)AV066135
CNPV*4824A** 0.96 0.92 315(A,J)AV066135 CNPV*6024A** 0.98 0.94 315(A,J)AV066135 CNPV*6124A** 0.99 0.95 315(A,J)AV066135
CSPH*4812A** 0.97 0.93 315(A,J)AV066135 CSPH*6012A** 0.98 0.94 315(A,J)AV066135
CAP**4824A** 0.96 0.92 315(A,J)AV066155 CAP**6024A** 0.98 0.94 315(A,J)AV066155
CNPH*4821A** 0.96 0.92 315(A,J)AV066155
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPH*6024A** 0.98 0.94 315(A,J)AV066155 CNPH*6124A** 0.98 0.94 315(A,J)AV066155
CNPV*4824A** 0.96 0.92 315(A,J)AV066155 CNPV*6024A** 0.98 0.94 315(A,J)AV066155 CNPV*6124A** 0.99 0.95 315(A,J)AV066155
CSPH*4812A** 0.97 0.93 315(A,J)AV066155 CSPH*6012A** 0.98 0.94 315(A,J)AV066155
CAP**4823A** 0.96 0.96 359BAV060080 CAP**6025A** 0.98 0.98 359BAV060080
CSPH*4812A** 0.97 0.97 359BAV060080 CSPH*6012A** 0.99 0.95 359BAV060080
CAP**6025A** 0.98 0.94 359BAV060100
CSPH*4812A** 0.97 0.97 359BAV060100 CSPH*6012A** 0.98 0.94 359BAV060100
CAP**4817A** 0.97 0.97 353AAV048080 CAP**4821A** 0.96 0.96 353AAV048080 CAP**6021A** 0.98 0.98 353AAV048080
CNPH*4821A** 0.96 0.96 353AAV048080 CNPH*6024A** 0.98 0.98 353AAV048080 CNPH*6124A** 0.98 0.94 353AAV048080
CNPV*4821A** 0.96 0.96 353AAV048080
CSPH*4812A** 0.97 0.97 353AAV048080 CSPH*6012A** 0.98 0.94 353AAV048080
CAP**4821A** 0.96 0.96 353AAV060100 CAP**4824A** 0.96 0.92 353AAV060100 CAP**6021A** 0.98 0.94 353AAV060100 CAP**6024A** 0.98 0.94 353AAV060100
CNPH*4821A** 0.97 0.93 353AAV060100 CNPH*6024A** 0.98 0.94 353AAV060100 CNPH*6124A** 0.98 0.94 353AAV060100
CNPV*4821A** 0.97 0.93 353AAV060100 CNPV*4824A** 0.97 0.93 353AAV060100 CNPV*6024A** 0.98 0.94 353AAV060100 CNPV*6124A** 0.99 0.95 353AAV060100
116B
