Bryant 116B - Condenser Only Ratings; TCG (Gross Cooling Capacity); SDT (Saturated Temperature Leaving Compressor); KW (Power Consumption)

53
CONDENSER ONLY RATINGS
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C )
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
116BNA018****B
30
( --- 1.11)
TCG 15.70 14.90 14.10 13.20 12.30 11.30 10.20 9.20
SDT 66.60 76.20 85.80 95.30 104.80 114.30 123.70 133.10
KW 0.75 0.87 0.99 1.12 1.26 1.41 1.60 1.81
35
(1.67)
TCG 17.50 16.60 15.70 14.70 13.70 12.60 11.50 10.30
SDT 67.80 77.30 86.80 96.30 105.70 115.10 124.40 133.80
KW 0.75 0.87 0.99 1.12 1.26 1.42 1.60 1.81
40
(4.44)
TCG 19.40 18.40 17.40 16.30 15.20 14.00 12.80 11.50
SDT 69.00 78.50 87.90 97.30 106.60 115.90 125.20 134.50
KW 0.74 0.87 0.99 1.12 1.26 1.42 1.60 1.81
45
(7.22)
TCG 21.50 20.30 19.20 18.00 16.70 15.50 14.10 12.80
SDT 70.40 79.70 89.00 98.30 107.60 116.90 126.10 135.30
KW 0.74 0.86 0.99 1.13 1.27 1.43 1.61 1.82
50
(10.0)
TCG 23.60 22.40 21.10 19.70 18.40 17.00 15.60 14.10
SDT 71.60 80.90 90.10 99.40 108.60 117.80 127.00 136.20
KW 0.73 0.86 1.00 1.13 1.28 1.44 1.62 1.82
55
(12.78)
TCG 25.90 24.50 23.10 21.60 20.10 18.60 17.10 15.50
SDT 73.00 82.10 91.30 100.50 109.70 118.80 128.00 137.10
KW 0.73 0.86 1.00 1.14 1.29 1.45 1.63 1.84
116BNA024****A
30
( --- 1.11)
TCG 20.30 19.40 18.30 17.20 16.10 14.80 13.60 12.20
SDT 66.10 75.80 85.30 94.90 104.40 114.00 123.40 132.80
KW 1.00 1.15 1.30 1.47 1.65 1.85 2.09 2.36
35
(1.67)
TCG 22.60 21.40 20.30 19.10 17.80 16.50 15.10 13.60
SDT 67.20 76.80 86.30 95.80 105.30 114.70 124.10 133.50
KW 0.99 1.14 1.30 1.47 1.65 1.86 2.09 2.36
40
(4.44)
TCG 24.90 23.70 22.40 21.00 19.60 18.20 16.70 15.10
SDT 68.40 77.90 87.30 96.70 106.10 115.50 124.80 134.10
KW 0.98 1.14 1.30 1.47 1.66 1.86 2.09 2.36
45
(7.22)
TCG 27.40 26.00 24.60 23.10 21.60 20.10 18.40 16.70
SDT 69.60 79.00 88.30 97.70 107.00 116.30 125.60 134.90
KW 0.97 1.14 1.30 1.48 1.66 1.87 2.10 2.37
50
(10.0)
TCG 30.10 28.60 27.00 25.40 23.70 22.00 20.20 18.40
SDT 70.80 80.10 89.40 98.70 107.90 117.20 126.40 135.60
KW 0.96 1.13 1.30 1.48 1.67 1.88 2.11 2.37
55
(12.78)
TCG 33.00 31.30 29.50 27.70 25.90 24.10 22.10 20.20
SDT 72.10 81.30 90.50 99.70 108.90 118.10 127.30 136.40
KW 0.95 1.13 1.31 1.49 1.68 1.89 2.12 2.39
116BNA030****A
30
( --- 1.11)
TCG 24.90 23.50 22.20 20.80 19.40 17.90 16.20 14.40
SDT 68.10 77.50 87.00 96.40 105.80 115.10 124.40 133.60
KW 1.27 1.43 1.60 1.78 1.99 2.23 2.50 2.81
35
(1.67)
TCG 27.50 26.00 24.50 23.10 21.50 19.90 18.10 16.20
SDT 69.40 78.70 88.10 97.40 106.70 116.00 125.30 134.40
KW 1.28 1.44 1.61 1.79 2.00 2.24 2.51 2.82
40
(4.44)
TCG 30.30 28.60 27.10 25.50 23.80 22.00 20.10 18.10
SDT 70.70 79.90 89.20 98.50 107.70 117.00 126.20 135.30
KW 1.29 1.44 1.61 1.80 2.01 2.25 2.52 2.83
45
(7.22)
TCG 33.30 31.50 29.80 28.00 26.20 24.30 22.30 20.10
SDT 72.00 81.20 90.40 99.60 108.80 118.00 127.20 136.30
KW 1.29 1.44 1.61 1.80 2.01 2.26 2.53 2.85
50
(10.0)
TCG 36.50 34.50 32.60 30.70 28.80 26.70 24.50 22.20
SDT 73.50 82.50 91.70 100.80 110.00 119.20 128.20 137.20
KW 1.29 1.44 1.61 1.80 2.02 2.26 2.54 2.86
55
(12.78)
TCG 39.90 37.80 35.70 33.60 31.50 29.30 26.90 24.40
SDT 75.00 84.00 93.00 102.10 111.20 120.30 129.30 138.20
KW 1.29 1.44 1.61 1.80 2.02 2.27 2.54 2.86
116BNA036****A
30
( --- 1.11)
TCG 31.50 29.90 28.30 26.60 24.80 22.90 21.00 18.90
SDT 68.90 78.20 87.50 96.80 106.20 115.50 124.90 134.20
KW 1.50 1.73 1.96 2.21 2.50 2.82 3.21 3.66
35
(1.67)
TCG 34.80 33.00 31.20 29.40 27.40 25.40 23.30 21.10
SDT 70.10 79.30 88.60 97.90 107.20 116.50 125.80 135.00
KW 1.50 1.73 1.97 2.22 2.51 2.83 3.21 3.66
40
(4.44)
TCG 38.30 36.40 34.40 32.40 30.30 28.10 25.80 23.40
SDT 71.40 80.60 89.80 99.00 108.20 117.40 126.70 135.90
KW 1.51 1.74 1.98 2.24 2.52 2.85 3.22 3.66
45
(7.22)
TCG 42.10 40.00 37.80 35.60 33.30 30.90 28.40 25.80
SDT 72.80 81.90 91.00 100.20 109.40 118.50 127.70 136.80
KW 1.52 1.75 1.99 2.25 2.54 2.86 3.24 3.67
50
(10.0)
TCG 46.20 43.90 41.50 39.00 36.50 33.90 31.20 28.40
SDT 74.40 83.30 92.40 101.50 110.50 119.60 128.70 137.70
KW 1.53 1.77 2.01 2.27 2.56 2.88 3.25 3.68
55
(12.78)
TCG 50.50 47.90 45.30 42.70 39.90 37.10 34.20 31.10
SDT 76.00 84.90 93.80 102.80 111.80 120.80 129.80 138.70
KW 1.55 1.79 2.04 2.30 2.58 2.91 3.28 3.70
See n otes on page 54
116B
