Bryant 165A User Manual

2
MODEL NUMBER NOMENCLATURE
1234 5 678910111214
NNNAA/NNNNNA/NA/NNA
165A N A036000A
Product
Family
Tier SEER Major Se-
ries
Voltage Variations Cooling Capacity Open Open Open Minor
Series
1=AC 6=
Preferred
Series
5=15
SEER
Nominal
A=Puron N=
208---230---1
A=
Standard
0=Not
Defined
0=
Not
Defined
0=
Not
Defined
A=
Original
Series
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and manufactured to
meet Energy Star® criteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
STANDARD FEATURES
Feature 018---B 024---B 030---B 036---B 042---B 048---B 060---B
Puron® Refrigerant X X X X X X X
Up to 16.5 SEER X X X X X X X
S t a n d a r d t h e r m o s t a t w / 3 --- o r 2 --- w i r e 2 4 v
connections to outdoor unit.
X X X X X X X
Scroll Compressor X X X X X X X
FieldInstalled16cu.in.FilterDrier X X X X X X X
Back Seating Service Valves X X X X X X X
High ---pressure Switch X X X X X X X
L o w --- p r e s s u r e S w i t c h X X X X X X X
Internal Pressure Relief Valve X X X X X X X
Internal Thermal Overload X X X X X X X
Long Line capability X X X X X X X
Low---ambient capability to 0° F
w/Complete System
X X X X X X X
Up to 14 Diagnostic Check---Points X X X X X X X
Utility Interface Connectio ns X X X X X X X
165A

Bryant 165A Specifications

Electrical Requirements

nominal unit electrical characteristics	single phase, 60 hz
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor type	hermetically sealed
condenser coil material	aluminum fins and copper tubes
