Bryant 165A User Manual

38
CONDENSER ONLY RATINGS*
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
165ANA018--- B
30
( --- 1.11)
TCG 16.50 15.50 14.60 13.60 12.60 11.60 10.50 9.40
SDT 65.80 75.30 84.80 94.40 103.90 113.40 122.90 132.40
KW 0.80 0.91 1.04 1.18 1.34 1.50 1.68 1.87
35
(1.67)
TCG 18.20 17.10 16.10 15.10 14.00 12.90 11.70 10.50
SDT 66.80 76.20 85.70 95.20 104.70 114.10 123.60 133.10
KW 0.80 0.91 1.04 1.18 1.33 1.50 1.69 1.88
40
(4.44)
TCG 20.00 18.90 17.70 16.60 15.50 14.30 13.00 11.70
SDT 67.80 77.20 86.60 96.10 105.50 114.90 124.40 133.80
KW 0.79 0.91 1.03 1.18 1.33 1.50 1.69 1.89
45
(7.22)
TCG 21.90 20.70 19.50 18.30 17.00 15.70 14.40 13.00
SDT 68.80 78.20 87.60 97.00 106.40 115.80 125.10 134.50
KW 0.79 0.90 1.03 1.17 1.33 1.50 1.69 1.89
50
(10.0)
TCG 23.90 22.60 21.30 20.00 18.70 17.30 15.80 14.30
SDT 70.00 79.30 88.70 98.00 107.30 116.60 125.90 135.20
KW 0.78 0.90 1.03 1.17 1.33 1.50 1.69 1.89
55
(12.78)
TCG 26.10 24.70 23.30 21.80 20.30 18.80 17.30 15.70
SDT 71.10 80.40 89.80 99.00 108.30 117.50 126.70 135.90
KW 0.78 0.89 1.02 1.17 1.33 1.50 1.69 1.89
165ANA024--- B
30
( --- 1.11)
TCG 21.30 20.10 18.90 17.70 16.50 15.20 13.90 12.60
SDT 68.90 78.20 87.60 97.00 106.40 115.90 125.30 134.80
KW 0.99 1.13 1.30 1.48 1.68 1.90 2.14 2.40
35
(1.67)
TCG 23.50 22.20 20.90 19.60 18.20 16.90 15.50 14.00
SDT 70.10 79.40 88.70 98.10 107.40 116.80 126.20 135.50
KW 0.99 1.14 1.30 1.48 1.68 1.91 2.15 2.41
40
(4.44)
TCG 25.80 24.40 23.00 21.60 20.10 18.60 17.10 15.50
SDT 71.40 80.60 89.90 99.20 108.50 117.80 127.10 136.30
KW 1.00 1.14 1.31 1.49 1.69 1.91 2.16 2.42
45
(7.22)
TCG 28.20 26.70 25.20 23.60 22.10 20.40 18.80 17.10
SDT 72.80 81.90 91.10 100.30 109.60 118.80 128.00 137.10
KW 1.00 1.15 1.31 1.50 1.70 1.92 2.16 2.43
50
(10.0)
TCG 30.80 29.10 27.50 25.80 24.10 22.30 20.50 18.60
SDT 74.20 83.30 92.40 101.60 110.70 119.80 128.90 138.00
KW 1.01 1.15 1.32 1.50 1.70 1.93 2.17 2.44
55
(12.78)
TCG 33.50 31.70 29.80 28.00 26.10 24.20 22.30 20.20
SDT 75.70 84.80 93.80 102.80 111.80 120.90 129.90 138.80
KW 1.01 1.16 1.33 1.51 1.71 1.93 2.18 2.44
165ANA030--- B
30
( --- 1.11)
TCG 26.40 25.00 23.50 22.10 20.50 19.00 17.30 15.50
SDT 68.50 77.80 87.20 96.60 106.00 115.40 124.80 134.20
KW 1.31 1.49 1.69 1.91 2.15 2.42 2.70 2.99
35
(1.67)
TCG 29.00 27.50 26.00 24.40 22.80 21.10 19.30 17.40
SDT 69.70 79.00 88.40 97.70 107.10 116.40 125.70 135.10
KW 1.32 1.50 1.70 1.92 2.16 2.43 2.72 3.02
40
(4.44)
TCG 31.90 30.30 28.60 26.90 25.20 23.40 21.40 19.40
SDT 71.10 80.30 89.60 98.90 108.10 117.40 126.70 135.90
KW 1.32 1.50 1.70 1.93 2.17 2.44 2.73 3.04
45
(7.22)
TCG 35.00 33.20 31.50 29.60 27.70 25.80 23.70 21.50
SDT 72.50 81.70 90.90 100.10 109.30 118.50 127.70 136.90
KW 1.33 1.51 1.71 1.94 2.18 2.45 2.75 3.06
50
(10.0)
TCG 38.30 36.40 34.50 32.50 30.50 28.30 26.10 23.80
SDT 74.00 83.10 92.20 101.30 110.50 119.60 128.70 137.80
KW 1.34 1.52 1.72 1.95 2.19 2.46 2.76 3.08
55
(12.78)
TCG 41.80 39.80 37.70 35.50 33.40 31.10 28.70 26.20
SDT 75.50 84.60 93.60 102.70 111.80 120.80 129.80 138.80
KW 1.35 1.53 1.73 1.96 2.20 2.48 2.77 3.10
165ANA036--- B
30
( --- 1.11)
TCG 35.70 33.80 31.80 29.80 27.70 25.50 23.20 20.80
SDT 68.30 77.50 86.70 96.00 105.30 114.60 123.90 133.20
KW 1.55 1.75 1.98 2.23 2.50 2.80 3.11 3.44
35
(1.67)
TCG 39.30 37.20 35.10 32.90 30.70 28.30 25.80 23.20
SDT 69.60 78.70 87.90 97.10 106.30 115.60 124.80 134.00
KW 1.56 1.76 1.99 2.24 2.51 2.81 3.14 3.48
40
(4.44)
TCG 43.20 40.90 38.60 36.30 33.80 31.30 28.60 25.70
SDT 71.00 80.00 89.10 98.20 107.40 116.60 125.70 134.80
KW 1.57 1.77 2.00 2.25 2.53 2.83 3.16 3.50
45
(7.22)
TCG 47.30 44.90 42.40 39.80 37.20 34.40 31.50 28.30
SDT 72.50 81.40 90.40 99.40 108.50 117.60 126.70 135.70
KW 1.58 1.78 2.01 2.26 2.54 2.85 3.18 3.53
50
(10.0)
TCG 51.70 49.00 46.30 43.60 40.70 37.70 34.50 31.10
SDT 74.00 82.80 91.80 100.70 109.70 118.70 127.70 136.60
KW 1.60 1.80 2.02 2.28 2.56 2.86 3.19 3.55
55
(12.78)
TCG 56.30 53.50 50.50 47.50 44.30 41.10 37.60 33.90
SDT 75.70 84.40 93.20 102.10 111.00 119.90 128.70 137.50
KW 1.61 1.81 2.04 2.29 2.57 2.88 3.21 3.57
See notes on page 39
165A

Bryant 165A Specifications

Electrical Requirements

nominal unit electrical characteristics	single phase, 60 hz
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor type	hermetically sealed
condenser coil material	aluminum fins and copper tubes
