28
DETAILED COOLING CAPACITIES# CONTINUED
165ANA024--- B Outdoor Section With CAP**3014A** Indoor Section
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CAP**3621A** 1.00 0.92 355AAV042040
CNPH*2417A** 0.98 0.90 355AAV042040 CNPH*3017A** 1.00 0.92 355AAV042040 CNPH*3617A** 1.00 0.92 355AAV042040
CNPV*3621A** 1.00 0.92 355AAV042040
CSPH*2412A** 1.00 0.92 355AAV042040 CSPH*3012A** 1.00 0.92 355AAV042040 CSPH*3612A** 1.01 0.93 355AAV042040
CAP**2417A** 0.98 0.90 355AAV042060 CAP**3017A** 1.00 0.92 355AAV042060 CAP**3614A** 1.00 0.92 355AAV042060 CAP**3617A** 1.00 0.92 355AAV042060 CAP**3621A** 1.00 0.92 355AAV042060
CNPH*2417A** 0.98 0.90 355AAV042060 CNPH*3017A** 1.00 0.92 355AAV042060 CNPH*3617A** 1.00 0.92 355AAV042060
CNPV*2417A** 0.98 0.90 355AAV042060 CNPV*3017A** 1.00 0.92 355AAV042060 CNPV*3617A** 1.00 0.92 355AAV042060 CNPV*3621A** 1.00 0.92 355AAV042060
CSPH*2412A** 1.00 0.92 355AAV042060 CSPH*3012A** 1.00 0.92 355AAV042060 CSPH*3612A** 1.01 0.93 355AAV042060
CAP**3617A** 1.00 0.92 355AAV042080 CAP**3621A** 1.00 0.92 355AAV042080
CNPH*2417A** 0.98 0.90 355AAV042080 CNPH*3017A** 1.00 0.92 355AAV042080 CNPH*3617A** 1.00 0.92 355AAV042080
CNPV*3617A** 1.00 0.92 355AAV042080 CNPV*3621A** 1.00 0.92 355AAV042080
CSPH*2412A** 1.00 0.92 355AAV042080 CSPH*3012A** 1.00 0.92 355AAV042080 CSPH*3612A** 1.01 0.93 355AAV042080
CAP**3617A** 1.00 0.92 355AAV060080 CAP**3621A** 1.00 0.92 355AAV060080
CNPH*2417A** 0.98 0.90 355AAV060080 CNPH*3017A** 1.00 0.92 355AAV060080 CNPH*3617A** 1.00 0.92 355AAV060080
CNPV*3617A** 1.00 0.92 355AAV060080 CNPV*3621A** 1.00 0.92 355AAV060080
CSPH*2412A** 1.00 0.92 355AAV060080 CSPH*3012A** 1.00 0.92 355AAV060080 CSPH*3612A** 0.98 0.91 355AAV060080
CAP**3617A** 1.00 0.92 355AAV060100 CAP**3621A** 1.00 0.92 355AAV060100
CNPH*2417A** 0.99 0.91 355AAV060100 CNPH*3017A** 1.00 0.92 355AAV060100 CNPH*3617A** 1.00 0.92 355AAV060100
CNPV*3617A** 1.00 0.92 355AAV060100 CNPV*3621A** 1.00 0.92 355AAV060100
CSPH*2412A** 1.00 0.92 355AAV060100 CSPH*3012A** 1.00 0.92 355AAV060100 CSPH*3612A** 1.02 0.94 355AAV060100
CAP**3621A** 1.00 0.92 355AAV060120
CNPH*2417A** 0.98 0.91 355AAV060120 CNPH*3017A** 0.99 0.91 355AAV060120 CNPH*3617A** 0.99 0.91 355AAV060120
CNPV*3621A** 1.00 0.92 355AAV060120
CSPH*2412A** 0.99 0.91 355AAV060120
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CSPH*3012A** 1.00 0.92 355AAV060120 CSPH*3612A** 1.01 0.93 355AAV060120
CAP**2414A** 0.99 0.95 313*AV024045 CAP**3014A** 1.01 0.93 313*AV024045
CNPH*2417A** 0.99 0.95 313*AV024045 CNPH*3017A** 1.00 0.92 313*AV024045
CNPV*2414A** 0.99 0.95 313*AV024045 CNPV*3014A** 1.00 0.92 313*AV024045
CSPH*2412A** 0.99 0.95 313*AV024045 CSPH*3012A** 1.01 0.93 313*AV024045
CNPV*2414A** 0.99 0.92 368RAN036105 CNPV*2417A** 0.99 0.92 368RAN036105 CNPV*3014A** 0.97 0.90 368RAN036105 CNPV*3017A** 0.97 0.90 368RAN036105 CNPV*2414A** 0.98 0.94 374RAN036105 CNPV*2417A** 0.98 0.94 374RAN036105 CNPV*3014A** 0.99 0.92 374RAN036105 CNPV*3017A** 1.00 0.92 374RAN036105
See notes on pg. 37
165A

Bryant 165A Specifications

Electrical Requirements

nominal unit electrical characteristics	single phase, 60 hz
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor type	hermetically sealed
condenser coil material	aluminum fins and copper tubes
