Bryant 165A User Manual

32
DETAILED COOLING CAPACITIES# CONTINUED
165ANA036--- B Outdoor Section With CAP**4221A** Indoor Section
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CNPV*3617A** 1.00 0.98 353AAV048080 CNPV*4217A** 1.00 0.96 353AAV048080
CSPH*3612A** 1.00 0.98 353AAV048080 CSPH*4212A** 1.00 0.96 353AAV048080
CAP**3621A** 1.00 0.96 353AAV060100 CAP**4221A** 1.00 0.96 353AAV060100
CNPH*3617A** 0.99 0.95 353AAV060100 CNPH*4221A** 1.00 0.96 353AAV060100
CNPV*3621A** 1.00 0.96 353AAV060100 CNPV*4221A** 1.00 0.96 353AAV060100
CSPH*3612A** 1.00 0.96 353AAV060100 CSPH*4212A** 1.00 0.96 353AAV060100
CAP**4224A** 0.99 0.93 355(A,C)AV042040 CAP**4821A** 1.01 0.94 355(A,C)AV042040 CAP**4824A** 1.01 0.94 355(A,C)AV042040
CNPH*3617A** 0.98 0.94 355(A,C)AV042040 CNPH*4221A** 1.00 0.92 355(A,C)AV042040 CNPH*4821A** 1.01 0.94 355(A,C)AV042040
CNPV*4821A** 1.01 0.94 355(A,C)AV042040 CNPV*4824A** 1.01 0.94 355(A,C)AV042040
CSPH*3612A** 1.01 0.94 355(A,C)AV042040 CSPH*4212A** 1.02 0.94 355(A,C)AV042040 CSPH*4812A** 1.02 0.94 355(A,C)AV042040
CAP**3617A** 0.99 0.93 355(A,C)AV042060 CAP**4817A** 1.02 0.93 355(A,C)AV042060 CAP**4821A** 1.01 0.93 355(A,C)AV042060
CNPH*3617A** 0.99 0.93 355(A,C)AV042060 CNPH*4221A** 1.00 0.92 355(A,C)AV042060 CNPH*4821A** 1.01 0.93 355(A,C)AV042060
CNPV*3617A** 0.99 0.93 355(A,C)AV042060 CNPV*4217A** 1.00 0.96 355(A,C)AV042060 CNPV*4821A** 1.01 0.93 355(A,C)AV042060
CSPH*3612A** 1.01 0.93 355(A,C)AV042060 CSPH*4212A** 1.02 0.93 355(A,C)AV042060 CSPH*4812A** 1.02 0.94 355(A,C)AV042060
CAP**3621A** 0.99 0.95 355(A,C)AV042080 CAP**4221A** 0.99 0.94 355(A,C)AV042080 CAP**4817A** 1.01 0.94 355(A,C)AV042080 CAP**4821A** 1.01 0.94 355(A,C)AV042080 CAP**4824A** 1.01 0.94 355(A,C)AV042080
CNPH*3617A** 0.98 0.95 355(A,C)AV042080 CNPH*4221A** 1.00 0.93 355(A,C)AV042080 CNPH*4821A** 1.01 0.94 355(A,C)AV042080
CNPV*3621A** 0.98 0.94 355(A,C)AV042080 CNPV*4221A** 1.00 0.93 355(A,C)AV042080 CNPV*4821A** 1.01 0.94 355(A,C)AV042080 CNPV*4824A** 1.01 0.94 355(A,C)AV042080
CSPH*3612A** 1.01 0.97 355(A,C)AV042080 CSPH*4212A** 1.02 0.94 355(A,C)AV042080 CSPH*4812A** 1.02 0.94 355(A,C)AV042080
CAP**3621A** 0.99 0.93 355(A,C)AV060080 CAP**4221A** 1.00 0.93 355(A,C)AV060080 CAP**4817A** 1.02 0.93 355(A,C)AV060080 CAP**4821A** 1.01 0.93 355(A,C)AV060080 CAP**4824A** 1.01 0.93 355(A,C)AV060080
CNPH*3617A** 0.99 0.95 355(A,C)AV060080 CNPH*4221A** 1.00 0.92 355(A,C)AV060080 CNPH*4821A** 1.01 0.93 355(A,C)AV060080
CNPV*3621A** 0.99 0.95 355(A,C)AV060080
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CNPV*4221A** 1.00 0.92 355(A,C)AV060080 CNPV*4821A** 1.01 0.93 355(A,C)AV060080 CNPV*4824A** 1.01 0.93 355(A,C)AV060080
CSPH*3612A** 1.01 0.93 355(A,C)AV060080 CSPH*4212A** 1.02 0.93 355(A,C)AV060080 CSPH*4812A** 1.02 0.94 355(A,C)AV060080
CAP**3621A** 0.99 0.93 355(A,C)AV060100 CAP**4817A** 1.02 0.93 355(A,C)AV060100 CAP**4821A** 1.01 0.93 355(A,C)AV060100 CAP**4824A** 1.01 0.93 355(A,C)AV060100
CNPH*3617A** 0.99 0.93 355(A,C)AV060100 CNPH*4221A** 1.01 0.92 355(A,C)AV060100 CNPH*4821A** 1.02 0.93 355(A,C)AV060100
CNPV*3621A** 0.99 0.93 355(A,C)AV060100 CNPV*4221A** 1.01 0.92 355(A,C)AV060100 CNPV*4821A** 1.02 0.93 355(A,C)AV060100 CNPV*4824A** 1.02 0.93 355(A,C)AV060100
CSPH*3612A** 1.02 0.93 355(A,C)AV060100 CSPH*4212A** 1.02 0.94 355(A,C)AV060100 CSPH*4812A** 1.02 0.94 355(A,C)AV060100
CAP**4224A** 1.00 0.92 355(A,C)AV060120 CAP**4821A** 1.01 0.93 355(A,C)AV060120 CAP**4824A** 1.01 0.93 355(A,C)AV060120
CNPH*3617A** 0.99 0.93 355(A,C)AV060120 CNPH*4221A** 1.00 0.92 355(A,C)AV060120 CNPH*4821A** 1.01 0.93 355(A,C)AV060120
CNPV*4821A** 1.01 0.93 355(A,C)AV060120 CNPV*4824A** 1.01 0.93 355(A,C)AV060120
CSPH*3612A** 1.01 0.93 355(A,C)AV060120 CSPH*4212A** 1.02 0.93 355(A,C)AV060120 CSPH*4812A** 1.02 0.94 355(A,C)AV060120
CAP**3614A** 0.97 0.97 313*AV024045
CNPH*3617A** 0.99 0.99 313*AV024045 CNPH*4221A** 1.01 0.99 313*AV024045
CSPH*3612A** 0.99 0.99 313*AV024045 CSPH*4212A** 1.02 1.00 313*AV024045
CAP**3617A** 1.00 0.98 313*AV048070
CNPH*3617A** 1.00 0.98 313*AV048070 CNPH*4221A** 1.01 0.99 313*AV048070
CNPV*3617A** 1.00 0.98 313*AV048070 CNPV*4217A** 1.00 0.98 313*AV048070
CSPH*3612A** 1.00 0.98 313*AV048070 CSPH*4212A** 1.02 1.00 313*AV048070
CAP**3621A** 1.01 0.97 313*AV048090 CAP**4221A** 1.02 0.94 313*AV048090
CNPH*3617A** 1.01 0.96 313*AV048090 CNPH*4221A** 1.02 0.97 313*AV048090
CNPV*3621A** 1.01 0.96 313*AV048090 CNPV*4221A** 1.02 0.97 313*AV048090
CSPH*3612A** 1.01 0.97 313*AV048090 CSPH*4212A** 1.02 0.94 313*AV048090
CAP**3621A** 1.02 0.93 313*AV060110 CAP**4221A** 1.02 0.94 313*AV060110
CNPH*3617A** 1.01 0.96 313*AV060110 CNPH*4221A** 1.02 0.94 313*AV060110
CNPV*3621A** 1.01 0.96 313*AV060110 CNPV*4221A** 1.02 0.94 313*AV060110
CSPH*3612A** 1.02 0.93 313*AV060110 CSPH*4212A** 1.02 0.94 313*AV060110
COOLING
INDOOR MODEL
CAPACITY POWER FURNACE MODEL
CNPV*3617A** 0.99 1.03 368RAN036105 CNPV*3621A** 0.99 1.03 368RAN036105 CNPV*4221A** 1.00 1.00 368RAN036105 CNPV*3617A** 0.99 1.02 368RAN060120 CNPV*3621A** 0.99 1.02 368RAN060120 CNPV*4221A** 1.00 1.00 368RAN060120 CNPV*3617A** 0.98 1.02 374RAN036105 CNPV*3621A** 0.98 1.02 374RAN036105 CNPV*4221A** 1.00 1.00 374RAN036105 CNPV*3617A** 0.99 1.01 374RAN060120 CNPV*3621A** 0.99 1.01 374RAN060120
See notes on pg. 37
165A

Bryant 165A Specifications

Electrical Requirements

nominal unit electrical characteristics	single phase, 60 hz
control circuit voltage	24v

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor type	hermetically sealed
condenser coil material	aluminum fins and copper tubes
