12
DETAILED COOLING CAPACITIES#
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA024****A Outdoor Section With FE5ANB004 Indoor Section HI
600
57 (13.9) 23.20 23.20 1.44 22.56 22.56 1.61 21.84 21.84 1.78 21.04 21.04 1.97 20.15 20.15 2.18 19.16 19.16 2.42
62 (16.7) 24.71 21.27 1.45 23.80 20.91 1.61 22.81 20.52 1.79 21.72 20.09 1.98 20.54 19.62 2.19 19.25 19.09 2.42
63 (17.2)†† 25.25 17.63 1.45 24.32 17.24 1.62 23.31 16.82 1.79 22.20 16.36 1.98 20.98 15.87 2.19 19.63 15.33 2.42
67 (19.4) 27.32 18.31 1.46 26.32 17.92 1.63 25.23 17.50 1.81 24.03 17.05 2.00 22.71 16.56 2.20 21.27 16.02 2.44
72 (22.2) 30.22 15.27 1.49 29.11 14.86 1.65 27.90 14.41 1.83 26.58 13.93 2.02 25.14 13.42 2.23 23.56 12.86 2.46
650
57 (13.9) 23.95 23.95 1.45 23.27 23.27 1.61 22.51 22.51 1.79 21.68 21.68 1.98 20.74 20.74 2.19 19.69 19.69 2.43
62 (16.7) 25.18 22.28 1.46 24.24 21.92 1.62 23.21 21.52 1.80 22.09 21.09 1.99 20.88 20.61 2.19 19.73 19.73 2.43
63 (17.2)†† 25.73 18.34 1.46 24.76 17.94 1.62 23.71 17.51 1.80 22.55 17.05 1.99 21.29 16.55 2.20 19.91 16.01 2.43
67 (19.4) 27.84 19.06 1.47 26.79 18.66 1.64 25.65 18.24 1.81 24.40 17.78 2.00 23.04 17.29 2.21 21.56 16.75 2.44
72 (22.2) 30.76 15.76 1.49 29.60 15.34 1.66 28.35 14.89 1.83 26.98 14.40 2.02 25.49 13.88 2.23 23.86 13.32 2.47
700
57 (13.9) 24.64 24.64 1.46 23.92 23.92 1.62 23.13 23.13 1.80 22.25 22.25 1.99 21.27 21.27 2.20 20.18 20.18 2.44
62 (16.7) 25.60 23.27 1.46 24.63 22.90 1.63 23.57 22.50 1.80 22.42 22.06 1.99 21.31 21.31 2.20 20.21 20.21 2.44
63 (17.2)†† 26.15 19.02 1.47 25.15 18.63 1.63 24.05 18.19 1.81 22.86 17.73 2.00 21.56 17.22 2.20 20.14 16.67 2.44
67 (19.4) 28.28 19.79 1.48 27.19 19.39 1.65 26.01 18.97 1.82 24.73 18.51 2.01 23.33 18.01 2.22 21.80 17.46 2.45
72 (22.2) 31.24 16.24 1.50 30.04 15.81 1.67 28.73 15.35 1.84 27.32 14.87 2.03 25.79 14.34 2.24 24.11 13.78 2.47
800
57 (13.9) 25.86 25.86 1.47 25.08 25.08 1.64 24.22 24.22 1.82 23.27 23.27 2.01 22.21 22.21 2.22 21.03 21.03 2.45
62 (16.7) 26.32 25.19 1.48 25.30 24.81 1.64 24.26 24.26 1.82 23.31 23.31 2.01 22.25 22.25 2.22 21.06 21.06 2.45
63 (17.2)†† 26.85 20.36 1.48 25.78 19.95 1.65 24.62 19.52 1.82 23.37 19.04 2.01 22.01 18.53 2.22 20.53 17.98 2.45
67 (19.4) 29.01 21.22 1.50 27.85 20.81 1.66 26.60 20.38 1.83 25.25 19.92 2.02 23.79 19.41 2.23 22.19 18.87 2.46
72 (22.2) 32.01 17.15 1.52 30.74 16.72 1.68 29.36 16.26 1.86 27.88 15.77 2.04 26.27 15.24 2.25 24.53 14.67 2.49
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA024****A Outdoor Section With FE5ANB004 Indoor Section LOW
480
57 (13.9) 18.65 18.65 0.90 17.97 17.97 1.06 17.24 17.24 1.24 16.44 16.44 1.44 15.58 15.58 1.68 14.63 14.63 1.96
62 (16.7) 19.73 17.41 0.91 18.82 16.98 1.06 17.83 16.52 1.24 16.78 16.03 1.44 15.66 15.52 1.68 14.66 14.66 1.96
63 (17.2)†† 20.21 14.36 0.91 19.27 13.92 1.07 18.26 13.46 1.24 17.18 12.98 1.44 16.02 12.46 1.68 14.77 11.92 1.96
67 (19.4) 22.07 15.01 0.92 21.06 14.57 1.07 19.97 14.11 1.25 18.81 13.62 1.45 17.56 13.11 1.69 16.21 12.56 1.97
72 (22.2) 24.73 12.57 0.93 23.61 12.13 1.09 22.42 11.67 1.26 21.13 11.18 1.46 19.76 10.66 1.70 18.27 10.11 1.98
520
57 (13.9) 19.30 19.30 0.91 18.59 18.59 1.07 17.81 17.81 1.24 16.98 16.98 1.45 16.07 16.07 1.69 15.08 15.08 1.97
62 (16.7) 20.14 18.28 0.91 19.19 17.83 1.07 18.18 17.36 1.24 17.10 16.87 1.45 16.10 16.10 1.69 15.11 15.11 1.97
63 (17.2)†† 20.61 14.96 0.91 19.64 14.52 1.07 18.59 14.05 1.25 17.47 13.56 1.45 16.28 13.03 1.69 14.99 12.48 1.97
67 (19.4) 22.52 15.66 0.92 21.46 15.21 1.08 20.34 14.74 1.25 19.13 14.24 1.46 17.84 13.72 1.69 16.45 13.16 1.97
72 (22.2) 25.22 13.01 0.94 24.07 12.56 1.09 22.82 12.08 1.27 21.50 11.58 1.47 20.07 11.06 1.70 18.54 10.50 1.98
560
57 (13.9) 19.90 19.90 0.91 19.15 19.15 1.07 18.34 18.34 1.25 17.47 17.47 1.45 16.52 16.52 1.69 15.49 15.49 1.97
62 (16.7) 20.50 19.12 0.92 19.53 18.67 1.07 18.49 18.19 1.25 17.51 17.51 1.45 16.56 16.56 1.69 15.52 15.52 1.97
63 (17.2)†† 20.97 15.56 0.92 19.96 15.10 1.08 18.89 14.63 1.25 17.74 14.12 1.45 16.51 13.59 1.69 15.19 13.03 1.97
67 (19.4) 22.91 16.30 0.93 21.82 15.84 1.08 20.66 15.36 1.26 19.41 14.85 1.46 18.08 14.32 1.70 16.66 13.76 1.98
72 (22.2) 25.66 13.42 0.95 24.46 12.97 1.10 23.18 12.49 1.27 21.81 11.98 1.47 20.34 11.44 1.71 18.77 10.88 1.98
640
57 (13.9) 20.97 20.97 0.93 20.16 20.16 1.08 19.29 19.29 1.26 18.35 18.35 1.46 17.33 17.33 1.70 16.22 16.22 1.98
62 (16.7) 21.15 20.77 0.93 20.20 20.20 1.08 19.32 19.32 1.26 18.38 18.38 1.46 17.36 17.36 1.70 16.24 16.24 1.98
63 (17.2)†† 21.57 16.71 0.93 20.51 16.24 1.08 19.38 15.75 1.26 18.17 15.23 1.46 16.88 14.69 1.70 15.51 14.11 1.98
67 (19.4) 23.56 17.53 0.94 22.41 17.06 1.09 21.18 16.57 1.27 19.88 16.05 1.47 18.49 15.50 1.71 17.00 14.92 1.99
72 (22.2) 26.38 14.23 0.96 25.11 13.76 1.11 23.76 13.27 1.28 22.32 12.75 1.48 20.78 12.20 1.71 19.14 11.62 1.99
See notes on page 16
