DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA036****B Outdoor Section With FE5ANB004 Indoor Section HI
900
57 (13.9) 32.38 32.38 1.97 31.63 31.63 2.20 30.77 30.77 2.45 29.79 29.79 2.73 28.66 28.66 3.03 27.36 27.36 3.38
62 (16.7) 34.40 29.89 1.99 33.26 29.50 2.22 32.01 29.07 2.46 30.60 28.58 2.74 29.05 28.02 3.04 27.40 27.40 3.38
63 (17.2)†† 35.15 24.76 1.99 34.01 24.31 2.22 32.71 23.81 2.47 31.26 23.26 2.74 29.65 22.64 3.04 27.85 21.97 3.38
67 (19.4) 38.03 25.71 2.02 36.78 25.27 2.25 35.39 24.78 2.50 33.84 24.24 2.77 32.10 23.64 3.07 30.14 22.96 3.41
72 (22.2) 42.01 21.46 2.06 40.65 20.95 2.28 39.11 20.40 2.53 37.40 19.80 2.81 35.50 19.14 3.11 33.34 18.40 3.45
975
57 (13.9) 33.40 33.40 1.99 32.61 32.61 2.22 31.70 31.70 2.47 30.65 30.65 2.75 29.46 29.46 3.05 28.09 28.09 3.40
62 (16.7) 35.03 31.28 2.00 33.86 30.90 2.23 32.55 30.46 2.48 31.10 29.96 2.75 29.54 29.47 3.05 28.14 28.14 3.40
63 (17.2)†† 35.79 25.74 2.01 34.58 25.29 2.24 33.24 24.79 2.49 31.73 24.23 2.76 30.06 23.61 3.06 28.21 22.93 3.40
67 (19.4) 38.70 26.75 2.04 37.39 26.31 2.26 35.93 25.82 2.51 34.33 25.28 2.78 32.52 24.67 3.09 30.50 24.00 3.43
72 (22.2) 42.73 22.13 2.07 41.30 21.62 2.30 39.71 21.07 2.55 37.79 20.41 2.82 35.95 19.80 3.13 33.73 19.06 3.47
1050
57 (13.9) 34.34 34.34 2.01 33.50 33.50 2.24 32.54 32.54 2.49 31.44 31.44 2.76 30.19 30.19 3.07 28.75 28.75 3.41
62 (16.7) 35.59 32.64 2.02 34.38 32.25 2.25 33.04 31.81 2.49 31.58 31.37 2.77 30.24 30.24 3.07 28.79 28.79 3.41
63 (17.2)†† 36.34 26.69 2.03 35.07 26.23 2.25 33.69 25.73 2.50 32.13 25.17 2.77 30.42 24.56 3.07 28.51 23.88 3.41
67 (19.4) 39.27 27.77 2.05 37.91 27.32 2.28 36.40 26.83 2.53 34.74 26.29 2.80 32.89 25.69 3.10 30.81 25.01 3.44
72 (22.2) 43.34 22.78 2.09 41.86 22.28 2.32 40.21 21.72 2.56 38.12 21.02 2.83 36.34 20.44 3.14 34.04 19.70 3.48
1200
57 (13.9) 35.99 35.99 2.04 35.07 35.07 2.27 34.01 34.01 2.52 32.82 32.82 2.80 31.45 31.45 3.11 29.88 29.88 3.45
62 (16.7) 36.55 35.23 2.05 35.29 34.80 2.28 34.06 34.06 2.52 32.87 32.87 2.80 31.50 31.50 3.11 29.93 29.93 3.45
63 (17.2)†† 37.24 28.52 2.05 35.90 28.07 2.28 34.43 27.57 2.53 32.79 27.02 2.80 30.99 26.40 3.10 29.00 25.71 3.44
67 (19.4) 40.20 29.72 2.08 38.76 29.29 2.31 37.00 28.73 2.55 35.42 28.27 2.83 33.47 27.66 3.13 31.30 26.98 3.47
72 (22.2) 44.34 24.04 2.12 42.76 23.53 2.35 41.01 22.97 2.59 39.08 22.36 2.87 36.94 21.69 3.17 34.55 20.95 3.51
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA036****B Outdoor Section With FE5ANB004 Indoor Section LOW
720
57 (13.9) 25.36 25.36 1.27 22.91 22.91 1.42 20.54 20.54 1.59 18.24 18.24 1.78 16.03 16.03 1.99 13.91 13.91 2.23
62 (16.7) 26.35 24.12 1.26 23.51 22.13 1.42 20.80 20.21 1.59 18.28 18.28 1.78 16.06 16.06 1.99 13.93 13.93 2.23
63 (17.2)†† 26.96 19.75 1.26 24.05 18.01 1.42 21.26 16.33 1.59 18.59 14.72 1.77 16.06 13.17 1.99 13.67 11.70 2.23
67 (19.4) 29.37 20.64 1.25 26.20 18.84 1.41 23.16 17.11 1.57 20.27 15.44 1.75 17.52 13.85 1.96 14.91 12.32 2.20
72 (22.2) 32.68 17.05 1.24 29.16 15.45 1.39 25.79 13.91 1.55 22.58 12.45 1.73 19.53 11.05 1.93 16.63 9.72 2.17
780
57 (13.9) 26.18 26.18 1.27 23.63 23.63 1.43 21.16 21.16 1.59 18.78 18.78 1.78 16.49 16.49 1.98 14.28 14.28 2.22
62 (16.7) 26.85 25.32 1.27 23.94 23.25 1.42 21.20 21.20 1.59 18.81 18.81 1.77 16.52 16.52 1.98 14.31 14.31 2.22
63 (17.2)†† 27.45 20.59 1.27 24.45 18.79 1.42 21.59 17.05 1.59 18.86 15.38 1.78 16.28 13.79 1.99 13.84 12.26 2.23
67 (19.4) 29.87 21.53 1.26 26.62 19.67 1.41 23.51 17.87 1.57 20.55 16.15 1.75 17.74 14.50 1.96 15.09 12.92 2.20
72 (22.2) 33.22 17.64 1.25 29.61 15.99 1.40 26.16 14.41 1.55 22.88 12.91 1.73 19.76 11.47 1.93 16.81 10.11 2.17
840
57 (13.9) 26.93 26.93 1.27 24.29 24.29 1.43 21.73 21.73 1.59 19.27 19.27 1.77 16.89 16.89 1.98 14.62 14.62 2.22
62 (16.7) 27.30 26.48 1.27 24.36 24.30 1.43 21.77 21.77 1.59 19.30 19.30 1.77 16.92 16.92 1.98 14.64 14.64 2.22
63 (17.2)†† 27.87 21.41 1.27 24.80 19.55 1.42 21.88 17.76 1.59 19.10 16.04 1.78 16.47 14.39 1.99 13.99 12.81 2.23
67 (19.4) 30.31 22.40 1.26 26.98 20.48 1.41 23.81 18.63 1.57 20.79 16.85 1.76 17.93 15.14 1.96 15.23 13.51 2.20
72 (22.2) 33.69 18.21 1.25 30.00 16.52 1.40 26.48 14.90 1.56 23.13 13.36 1.73 19.96 11.88 1.94 16.96 10.48 2.17
960
57 (13.9) 28.26 28.26 1.28 25.45 25.45 1.43 22.73 22.73 1.59 20.11 20.11 1.77 17.60 17.60 1.98 15.20 15.20 2.21
62 (16.7) 28.31 28.31 1.28 25.49 25.49 1.43 22.77 22.77 1.59 20.15 20.15 1.77 17.63 17.63 1.98 15.22 15.22 2.21
63 (17.2)†† 28.56 23.00 1.28 25.38 21.03 1.43 22.36 19.13 1.60 19.49 17.31 1.78 16.78 15.55 1.99 14.25 13.86 2.24
67 (19.4) 31.01 24.10 1.27 27.57 22.07 1.42 24.29 20.10 1.58 21.18 18.22 1.76 18.24 16.40 1.97 15.48 14.65 2.21
72 (22.2) 34.45 19.30 1.26 30.63 17.53 1.41 26.99 15.84 1.56 23.54 14.22 1.74 20.27 12.68 1.94 17.20 11.21 2.17
See notes on page 16
