DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA048****A Outdoor Section With FE4ANB006 Indoor Section HI
1200
57 (13.9) 42.82 42.82 2.74 41.85 41.85 3.08 40.71 40.71 3.44 39.37 39.37 3.85 37.79 37.79 4.31 35.95 35.95 4.83
62 (16.7) 45.47 39.35 2.76 44.03 38.89 3.10 42.41 38.35 3.46 40.55 37.70 3.87 38.42 36.92 4.32 36.05 35.85 4.83
63 (17.2)†† 46.44 32.48 2.77 44.97 31.94 3.10 43.31 31.32 3.47 41.38 30.60 3.87 39.18 29.77 4.33 36.64 28.81 4.84
67 (19.4) 50.20 33.72 2.81 48.60 33.18 3.14 46.78 32.57 3.50 44.69 31.85 3.91 42.29 31.02 4.37 39.53 30.06 4.88
72 (22.2) 55.40 27.96 2.85 53.63 27.34 3.18 51.59 26.64 3.55 49.26 25.84 3.96 46.62 24.94 4.42 43.55 23.89 4.94
1300
57 (13.9) 44.10 44.10 2.77 43.07 43.07 3.11 41.86 41.86 3.47 40.44 40.44 3.88 38.77 38.77 4.34 36.80 36.80 4.86
62 (16.7) 46.25 41.12 2.79 44.75 40.66 3.12 43.08 40.11 3.49 41.16 39.44 3.89 39.01 38.59 4.35 36.86 36.86 4.86
63 (17.2)†† 47.21 33.70 2.80 45.68 33.16 3.13 43.91 32.52 3.49 41.95 31.82 3.90 39.66 30.98 4.35 37.06 30.01 4.86
67 (19.4) 51.01 35.02 2.83 49.34 34.49 3.16 47.43 33.87 3.53 45.13 33.09 3.93 42.80 32.32 4.39 39.94 31.35 4.91
72 (22.2) 56.27 28.79 2.88 54.41 28.17 3.21 52.29 27.46 3.58 49.90 26.66 3.99 47.14 25.74 4.45 44.00 24.69 4.96
1400
57 (13.9) 45.26 45.26 2.80 44.08 44.08 3.13 42.90 42.90 3.51 41.41 41.41 3.92 39.65 39.65 4.37 37.59 37.59 4.89
62 (16.7) 46.93 42.83 2.82 45.40 42.36 3.15 43.65 41.78 3.51 41.73 41.07 3.92 39.71 39.71 4.38 37.65 37.65 4.89
63 (17.2)†† 47.88 34.89 2.82 46.29 34.35 3.15 44.35 33.66 3.52 42.42 33.00 3.92 40.07 32.15 4.38 37.39 31.18 4.89
67 (19.4) 51.71 36.29 2.86 49.97 35.76 3.19 48.00 35.14 3.56 45.48 34.30 3.96 43.22 33.59 4.42 40.30 32.62 4.93
72 (22.2) 57.01 29.59 2.90 55.07 28.96 3.24 52.90 28.25 3.61 50.42 27.44 4.02 47.60 26.53 4.48 44.38 25.48 4.99
1600
57 (13.9) 47.30 47.30 2.86 46.09 46.09 3.19 44.61 44.61 3.56 42.91 42.91 3.97 41.17 41.17 4.44 38.90 38.90 4.96
62 (16.7) 48.11 46.07 2.86 46.52 45.54 3.20 44.78 44.78 3.56 43.13 43.13 3.97 41.22 41.22 4.44 38.99 38.99 4.96
63 (17.2)†† 48.96 37.17 2.87 47.27 36.63 3.20 45.35 36.00 3.57 43.19 35.27 3.97 40.74 34.43 4.43 37.94 33.42 4.94
67 (19.4) 52.83 38.74 2.91 50.99 38.21 3.24 48.90 37.59 3.60 46.54 36.87 4.01 43.90 36.04 4.47 40.86 35.05 4.98
72 (22.2) 58.20 31.12 2.95 56.17 30.49 3.29 53.85 29.77 3.66 51.25 28.96 4.07 48.30 28.04 4.53 44.95 26.97 5.04
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA048****A Outdoor Section With FE4ANB006 Indoor Section LOW
960
57 (13.9) 33.67 33.67 1.85 30.66 30.66 2.12 27.68 27.68 2.41 24.75 24.75 2.75 21.87 21.87 3.15 19.04 19.04 3.60
62 (16.7) 35.11 31.86 1.85 31.65 29.38 2.11 28.26 26.94 2.41 24.97 24.53 2.75 21.90 21.90 3.14 19.07 19.07 3.60
63 (17.2)†† 35.89 26.05 1.84 32.34 23.90 2.11 28.86 21.79 2.41 25.46 19.73 2.75 22.15 17.71 3.14 18.95 15.75 3.61
67 (19.4) 39.09 27.22 1.83 35.21 24.99 2.09 31.42 22.81 2.39 27.70 20.67 2.72 24.10 18.58 3.11 20.61 16.55 3.56
72 (22.2) 43.44 22.45 1.83 39.13 20.47 2.08 34.90 18.55 2.36 30.79 16.66 2.69 26.79 14.84 3.07 22.92 13.07 3.51
1040
57 (13.9) 34.72 34.72 1.86 31.60 31.60 2.12 28.51 28.51 2.42 25.45 25.45 2.75 22.46 22.46 3.14 19.54 19.54 3.60
62 (16.7) 35.74 33.38 1.85 32.21 30.80 2.12 28.76 28.24 2.42 25.50 25.50 2.75 22.50 22.50 3.14 19.57 19.57 3.60
63 (17.2)†† 36.50 27.12 1.85 32.87 24.90 2.12 29.30 22.72 2.41 25.82 20.58 2.75 22.44 18.50 3.15 19.17 16.47 3.61
67 (19.4) 39.72 28.36 1.84 35.75 26.05 2.10 31.86 23.79 2.39 28.07 21.58 2.73 24.39 19.42 3.11 20.84 17.32 3.57
72 (22.2) 44.13 23.18 1.84 39.71 21.15 2.09 35.15 19.08 2.37 31.18 17.24 2.70 27.10 15.36 3.07 23.15 13.55 3.52
1120
57 (13.9) 35.69 35.69 1.86 32.45 32.45 2.13 29.25 29.25 2.42 26.10 26.10 2.76 23.01 23.01 3.15 19.97 19.97 3.60
62 (16.7) 36.32 34.86 1.86 32.73 32.15 2.13 29.30 29.30 2.42 26.14 26.14 2.76 23.04 23.04 3.15 20.00 20.00 3.60
63 (17.2)†† 37.04 28.16 1.86 33.32 25.87 2.12 29.68 23.62 2.42 26.13 21.41 2.76 22.68 19.26 3.15 19.37 17.17 3.61
67 (19.4) 40.27 29.46 1.85 36.20 27.08 2.11 32.24 24.75 2.40 28.38 22.47 2.73 24.64 20.24 3.12 21.03 18.07 3.57
72 (22.2) 44.72 23.88 1.85 40.21 21.80 2.10 35.80 19.77 2.38 31.52 17.80 2.70 27.36 15.88 3.08 23.35 14.02 3.52
1280
57 (13.9) 37.37 37.37 1.88 33.94 33.94 2.14 30.54 30.54 2.43 27.20 27.20 2.77 23.92 23.92 3.15 20.72 20.72 3.60
62 (16.7) 37.49 37.37 1.88 0.00 0.00 0.00 30.59 30.59 2.43 27.24 27.24 2.77 23.96 23.96 3.15 20.75 20.75 3.60
63 (17.2)†† 37.90 30.17 1.88 34.05 27.74 2.14 30.29 25.35 2.44 26.63 23.02 2.77 23.09 20.74 3.17 19.70 18.50 3.63
67 (19.4) 41.15 31.61 1.87 36.95 29.09 2.13 32.87 26.62 2.42 28.89 24.19 2.75 25.04 21.83 3.13 21.35 19.52 3.58
72 (22.2) 45.67 25.24 1.87 41.01 23.07 2.12 36.46 20.94 2.40 32.05 18.88 2.72 27.78 16.87 3.10 23.66 14.93 3.54
See notes on page 16
