DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA060****A Outdoor Section With FE4ANB006 Indoor Section HI
1500
57 (13.9) 53.62 53.62 3.64 52.22 52.22 4.04 50.56 50.56 4.46 48.76 48.76 4.93 46.60 46.60 5.45 44.09 44.09 6.02
62 (16.7) 56.62 49.54 3.67 54.64 48.79 4.07 52.42 47.94 4.49 49.94 46.96 4.95 47.14 45.78 5.46 44.17 44.17 6.02
63 (17.2)†† 57.81 40.70 3.69 55.76 39.88 4.08 53.49 38.98 4.50 50.73 37.87 4.96 48.02 36.80 5.47 44.70 35.49 6.03
67 (19.4) 62.40 42.25 3.74 60.17 41.43 4.13 57.68 40.52 4.56 54.86 39.48 5.02 51.70 38.33 5.53 48.12 37.03 6.09
72 (22.2) 68.73 34.78 3.82 66.25 33.88 4.21 63.48 32.89 4.64 60.34 31.78 5.10 56.84 30.55 5.61 52.89 29.18 6.18
1625
57 (13.9) 55.12 55.12 3.69 53.63 53.63 4.09 51.93 51.93 4.52 49.98 49.98 4.99 47.68 47.68 5.50 45.08 45.08 6.08
62 (16.7) 57.51 51.70 3.72 55.44 50.93 4.11 53.18 50.06 4.53 50.46 48.92 4.99 47.86 47.66 5.51 45.13 45.13 6.08
63 (17.2)†† 58.67 42.19 3.73 56.55 41.37 4.12 54.18 40.45 4.55 51.51 39.41 5.01 48.52 38.25 5.51 45.13 36.93 6.07
67 (19.4) 63.30 43.83 3.79 60.99 43.01 4.18 58.40 42.09 4.60 55.49 41.05 5.07 52.23 39.89 5.57 48.56 38.58 6.14
72 (22.2) 69.69 35.77 3.86 67.12 34.87 4.26 64.23 33.86 4.68 61.01 32.74 5.15 57.40 31.50 5.66 53.35 30.13 6.22
1750
57 (13.9) 56.47 56.47 3.74 54.90 54.90 4.14 53.12 53.12 4.57 51.06 51.06 5.04 48.69 48.69 5.55 45.94 45.94 6.13
62 (16.7) 58.28 53.77 3.76 56.17 52.98 4.16 53.85 52.06 4.58 51.30 50.86 5.04 48.75 48.75 5.56 45.99 45.99 6.13
63 (17.2)†† 59.42 43.64 3.77 57.21 42.80 4.17 54.77 41.88 4.59 52.03 40.84 5.05 48.95 39.66 5.56 45.48 38.32 6.11
67 (19.4) 64.07 45.38 3.83 61.68 44.55 4.22 59.00 43.63 4.65 56.02 42.59 5.11 52.65 41.41 5.62 48.90 40.09 6.18
72 (22.2) 70.52 36.73 3.91 67.84 35.81 4.30 64.88 34.80 4.73 61.56 33.67 5.19 57.79 32.39 5.70 53.72 31.05 6.26
2000
57 (13.9) 58.82 58.82 3.84 57.09 57.09 4.24 55.16 55.16 4.67 52.92 52.92 5.13 50.34 50.34 5.65 47.39 47.39 6.22
62 (16.7) 59.62 57.64 3.85 57.46 56.69 4.24 55.23 55.23 4.67 52.99 52.99 5.14 50.20 50.20 5.65 47.45 47.45 6.22
63 (17.2)†† 60.59 46.39 3.86 58.27 45.56 4.25 55.70 44.62 4.67 52.81 43.56 5.13 49.48 42.30 5.63 46.03 40.98 6.19
67 (19.4) 65.29 48.35 3.92 62.77 47.52 4.31 59.96 46.59 4.73 56.82 45.53 5.19 53.33 44.34 5.70 49.45 42.98 6.26
72 (22.2) 71.82 38.55 3.99 69.03 37.63 4.39 65.88 36.60 4.81 62.41 35.46 5.27 58.54 34.19 5.78 54.26 32.81 6.34
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F (°C)
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Capacity MBtuh
Total
Sys.
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Total Sens‡ Tota l Sens‡
180BNA060****A Outdoor Section With FE4ANB006 Indoor Section LOW
1500
57 (13.9) 45.33 45.33 2.38 43.58 43.58 2.68 41.66 41.66 3.02 39.56 39.56 3.40 37.28 37.28 3.85 34.79 34.79 4.36
62 (16.7) 45.41 45.41 2.38 43.65 43.65 2.68 41.72 41.72 3.02 39.62 39.62 3.40 37.33 37.33 3.84 34.84 34.84 4.36
63 (17.2)†† 46.00 36.51 2.37 43.78 35.54 2.68 41.40 34.50 3.02 38.83 33.39 3.41 36.09 32.21 3.86 33.19 30.94 4.39
67 (19.4) 49.80 38.19 2.36 47.38 37.21 2.67 44.79 36.17 3.00 42.01 35.06 3.38 39.03 33.87 3.82 35.87 32.59 4.34
72 (22.2) 55.12 30.40 2.36 52.45 29.42 2.65 49.57 28.38 2.97 46.32 27.22 3.34 43.18 26.11 3.78 39.63 24.87 4.28
1625
57 (13.9) 46.43 46.43 2.39 44.60 44.60 2.70 42.60 42.60 3.03 40.42 40.42 3.42 38.05 38.05 3.86 35.46 35.46 4.36
62 (16.7) 46.50 46.50 2.39 44.66 44.66 2.70 42.66 42.66 3.03 40.47 40.47 3.42 38.09 38.09 3.85 35.50 35.50 4.36
63 (17.2)†† 46.51 38.02 2.39 44.25 37.04 2.70 41.80 35.97 3.04 39.18 34.84 3.43 36.40 33.62 3.88 33.47 32.28 4.40
67 (19.4) 50.33 39.82 2.38 47.86 38.83 2.68 45.20 37.76 3.02 42.37 36.62 3.40 39.35 35.40 3.84 36.15 34.08 4.35
72 (22.2) 55.69 31.41 2.38 52.95 30.42 2.67 50.00 29.37 2.99 46.55 28.15 3.36 43.48 27.08 3.80 39.88 25.83 4.30
1750
57 (13.9) 47.42 47.42 2.41 45.52 45.52 2.71 43.44 43.44 3.05 41.18 41.18 3.43 38.72 38.72 3.87 36.05 36.05 4.37
62 (16.7) 47.49 47.49 2.41 45.58 45.58 2.71 43.50 43.50 3.05 41.23 41.23 3.43 38.77 38.77 3.87 36.21 36.21 4.38
63 (17.2)†† 46.95 39.49 2.41 44.63 38.48 2.72 42.15 37.40 3.06 39.50 36.23 3.45 36.68 34.95 3.90 33.74 33.46 4.42
67 (19.4) 50.78 41.41 2.40 48.26 40.39 2.70 45.45 39.26 3.03 42.68 38.14 3.42 39.62 36.88 3.86 36.40 35.45 4.37
72 (22.2) 56.17 32.40 2.40 53.37 31.40 2.69 50.36 30.33 3.01 46.74 29.06 3.38 43.73 28.02 3.81 40.04 26.75 4.32
2000
57 (13.9) 49.13 49.13 2.45 46.89 46.89 2.75 44.88 44.88 3.08 42.47 42.47 3.46 39.86 39.86 3.89 37.03 37.03 4.40
62 (16.7) 49.19 49.19 2.45 46.94 46.94 2.75 44.93 44.93 3.08 42.51 42.51 3.46 39.90 39.90 3.89 37.09 37.09 4.40
63 (17.2)†† 47.67 42.29 2.45 45.28 41.23 2.76 42.74 40.08 3.10 40.04 38.79 3.48 37.23 37.23 3.93 34.54 34.54 4.44
67 (19.4) 51.51 44.45 2.45 48.92 43.38 2.74 45.87 42.11 3.07 43.21 40.98 3.45 40.13 39.51 3.89 37.11 37.11 4.40
72 (22.2) 56.91 34.30 2.44 54.01 33.28 2.73 50.92 32.20 3.05 47.60 31.05 3.42 44.08 29.85 3.85 40.31 28.56 4.35
See notes on page 16
