Bryant 225A - 225 A Balance Point Worksheet; Building Heat Loss vs. Unit Integrated Heating Capacity

10
225A BALANCE POINT WORKSHEET
0
10 20 30 40 50 60 70 80
BUILDING HEAT LOSS, UNIT INTEGRATED HEATING
CAPACITY, MBTUH
225ANA060 FX4CN(B,F)060 225ANA048 FX4CN(B,F)060 225ANA042 FX4CN(B,F)048 225ANA036 FX4CN(B,F)042 225ANA030 FX4CN(B,F)036 225ANA024 FX4CNF030 225ANA018 FX4CNF018
BASED ON INDOOR ENT. AIR AT 70ºF (21ºC) AND AT RATED CFM
-10 (-23)
0 (17.78) 10 (-12.22) 20 (-6.67) 30 (-1.11) 40 (4.44) 50 (10)
60 (15.56)
70 (21.11) 80 (26.67)
OUTDOOR TEMPERATURE, ºF (ºC)
