Bryant 225A User Manual

2
MODEL NUMBER NOMENCLATURE
1234 5 678910111214
N N N A A/N N N N N A/N A/N N A
22 5 A N A 036 0 0 0 A
Product
Family
Tier SEER Major
Series
Voltage Variations Cooling Capacity Open Open Open Series
2=HP 2=
Legacy
Series
5=15 SEER A=Puron N= 208---230---1
or 208/230 ---1
A = Standard 0=Not
Defined
0=Not
Defined
0=Not De-
fined
A=
Original
Series
the environmentally sound refrigerant
REGISTERED
ISO 9001:2000
This product has been designed and
manufactured to meet Energy Star® criteria for
energy efficiency when matched with
appropriate coil components. However, proper
refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency.
Installation of this product should follow all
manufacturing refrigerant charging and air flow
instructions. Failure to confirm proper charge
and air flow may reduce energy efficiency and
shorten equipment life.
STANDARD FEATURES
Feature 18 24 30 36 42 48 60
Puron Refrigerant X X X X X X X
15 SEER X X X X X X X
Scroll Compressor X X X X X X X
Louvered Coil Guard X X X X X X X
FieldInstalledFilterDrier X X X X X X X
Front Seating Service Valves X X X X X X X
Internal Pressure Relief Valve X X X X X X X
Internal Thermal Overload X X X X X X X
Long Line capability X X X X X X X
Low Am bient capability with Kit X X X X X X X
Suction Line Accumulator X X X X X X X
High Pressure Switch X X X X X X X
Loss of Charge Switch X X X X X X X
X = Standard
223A

Bryant 225A Specifications

Fans

condenser fan type	direct-drive propeller type
condenser fan motor type	1-phase type with class B insulation
condenser fan motor lubrication	permanently lubricated bearings

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor oil type	POE compressor oil
reversing valve	included

Electrical Requirements

control circuit voltage	24v
nominal unit electrical characteristics (single phase)	_ v, 60 hz
nominal unit electrical characteristics (three phase)	_ v, 60 hz
