Bryant 225A User Manual

3
PHYSICAL DATA
UNIT SIZE SERIES 018---B 024--- B 030---B 036---B 042--- B 048---B 060---B
Operating Weight lb (kg)
174
(79.0)
219
(99.3)
247
(112.0)
254
(115.2)
280
(127.0)
302
(134.0)
342
(155.1)
Shipping Weight lb (kg)
201
(91.2)
263
(119.3)
283
(128.4)
291
(132.0)
316
(143.3)
341
(154.7)
382
(173.3)
Compressor Type Scroll
REFRIGERANT Puron (R---410A)
Control TXV (Puron Hard Shutoff)
Charge lb (kg) 6.4 (2.9) 7.3 (3.3) 11.2 (5.1) 13.2 (6.0) 11.9 (5.4) 13.5 (6.1) 16.2 (7.4)
Outdoor Piston no. 42 46 52 52 59 67 76
COND FAN Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 2614 3223 3334 3810 3810 4046 4046
Motor HP 1/10 1/12 1/8 1/5 1/5 1/4 1/4
Motor RPM 800 800 800 800 800 800 800
COND COIL
Face Area (Sq ft) 15.09 25.15 20.12 22.63 25.15 25.15 30.18
Fins per In. 20 20 20 20 20 20 20
Rows 1 1 2 2 2 2 2
Circuits 5 5 6 6 6 8 10
VALVECONNECT.(In.ID)
Vapor 5/8 5/8 3/4 3/4 7/8 7/8 7/8
Liquid 3/8
REFRIGERANT TUBES ( In. OD)
Rated Vapor* 5/8 5/8 3/4 3/4 7/8 7/8 1 --- 1 / 8
Liquid 3/8”
*Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
Note: See unit Installation Instruction for proper installation.
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
LONG LINE APPLICATION: An application is considered
”Long line” when the total equivalent tubing length exceeds 80
ft. (24.38 m) or when there is more than 20 ft. (6.09 m) vertical
separation between indoor and outdoor units. These applications
require additional accessories and system modifications for
reliable system operation. The maximum allowable total
equivalent length is up to 250 ft. (76.2 m). The maximum
vertical separation is 200 ft. (60.96 m) when outdoor unit is
above indoor unit, and up to 80 ft. (24.38 m) when the outdoor
unit is below the indoor unit. Refer to Accessory Usage Guideline
below for required accessories. See Longline Application
Guideline for required piping and system modifications. Also,
refer to the table below for vapor tube diameters based on the
total length to minimize the cooling capacity loss.
Unit Nominal Size
(Btuh)
Maximum
Liquid Line
Diameters
(In.) OD
Vapor Line
Diameters
(In.) OD
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. ( m)
Standard
Application
Long Line Application Requires Accessories
26--- 50
(7.9--- 15.2)
51--- 80
(15.5--- 24.4)
81--- 100
(24.7--- 30.5)
101--- 125
(30.8--- 38.1)
126--- 150
(38.4--- 45.7)
151--- 175
(46.0--- 50.3)
176--- 200
(53.6--- 60.0)
201--- 225
(61.3--- 68.6)
226--- 250
(68.9--- 76.2)
18,000
1 --- S t a g e P u r o n H P
3/8
1/2 1 2 3 4 6 7 8 9 10
5/8 0 0 1 1 1 2 2 3 3
24,000
1 --- S t a g e P u r o n H P
5/8 0 1 1 2 3 3 4 4 5
3/4 0 0 0 0 1 1 1 1 1
30,000
1 --- S t a g e P u r o n H P
5/8 1 2 3 3 4 5 6 7 8
3/4 0 0 1 1 1 2 2 2 3
7/8 0 0 0 0 1 1 1 1 1
36,000
1 --- S t a g e P u r o n H P
5/8 1 2 4 5 6 7 9 10 11
3/4 0 0 1 1 2 2 3 3 4
7/8 0 0 0 0 1 1 1 1 2
42,000
1 --- S t a g e P u r o n H P
3/4 0 1 2 2 3 4 4 5 6
7/8 0 0 1 1 1 2 2 2 3
48,000
1 --- S t a g e P u r o n H P
3/4 0 1 2 3 4 5 5 6 7
7/8 0 0 1 1 2 2 2 3 3
60,000
1 --- S t a g e P u r o n H P
3/4 1 2 4 5 6 7 9 10 11
7/8 0 1 2 2 3 4 4 5 5
1 --- 1 / 8 0 0 0 1 1 1 1 1 1
Applications in this area are long line. Accessories are required as shown recommended on Long Line Application Guidelines
Applications in this area may have height restrictions that limit allowable total equivalent length, when outdoor unit is below indoor unit See Long Line Applica-
tion Guidelines
223A

Bryant 225A Specifications

Fans

condenser fan type	direct-drive propeller type
condenser fan motor type	1-phase type with class B insulation
condenser fan motor lubrication	permanently lubricated bearings

Refrigeration Components

refrigerant type	Puronr (R-410A)
compressor oil type	POE compressor oil
reversing valve	included

Electrical Requirements

control circuit voltage	24v
nominal unit electrical characteristics (single phase)	_ v, 60 hz
nominal unit electrical characteristics (three phase)	_ v, 60 hz
