27
DETAI LED COOLING CAPACITIES
#
CONTINUED
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Tot a l
System
KW**
Capacity MBtuh
Tot a l
System
KW**
Capacity MBtuh
Tot a l
System
KW**
Capacity MBtuh
Tot a l
System
KW**
Capacity MBtuh
Tot a l
System
KW**
Capacity MBtuh
Tot a l
System
KW**
Tot a l Sens‡ Tot a l Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ Tot a l Sens‡
225A*A036--- BOutdoor Section With FX4CN(B,F)042 Indoor Section
1050
72 (22.2) 42.37 21.63 2.26 40.45 20.88 2.51 38.43 20.10 2.79 36.27 19.28 3.09 33.93 18.40 3.42 31.45 17.48 3.77 67 (19.4) 38.48 26.77 2.26 36.70 26.00 2.50 34.82 25.19 2.77 32.83 24.35 3.08 30.67 23.44 3.40 28.41 22.51 3.76
63 (17.2)†† 35.67 25.84 2.25 34.00 25.07 2.49 32.23 24.26 2.77 30.35 23.40 3.07 28.32 22.49 3.39 26.21 21.56 3.75
62 (16.7) 34.97 31.89 2.25 33.34 31.07 2.49 31.63 30.21 2.76 29.83 29.27 3.06 27.99 27.99 3.39 26.30 26.30 3.75 57 (13.9) 33.76 33.76 2.24 32.46 32.46 2.49 31.08 31.08 2.76 29.60 29.60 3.06 27.99 27.99 3.39 26.30 26.30 3.75
1200
72 (22.2) 43.17 22.62 2.32 41.17 21.86 2.57 39.06 21.06 2.84 36.81 20.22 3.15 34.38 19.33 3.47 31.81 18.39 3.83 67 (19.4) 39.21 28.41 2.31 37.35 27.62 2.56 35.40 26.81 2.83 33.32 25.94 3.13 31.09 25.02 3.46 28.75 24.06 3.82
63 (17.2)†† 36.35 27.38 2.30 34.61 26.59 2.55 32.77 25.76 2.82 30.82 24.89 3.12 28.72 23.96 3.45 26.54 22.99 3.81
62 (16.7) 35.71 34.09 2.30 34.04 33.21 2.55 32.29 32.24 2.82 30.68 30.68 3.12 28.98 28.98 3.45 27.17 27.17 3.81 57 (13.9) 35.09 35.09 2.30 33.71 33.71 2.55 32.25 32.25 2.82 30.68 30.68 3.12 28.98 28.98 3.45 27.18 27.18 3.81
1350
72 (22.2) 43.76 23.54 2.38 41.70 22.77 2.63 39.52 21.97 2.90 37.20 21.12 3.20 34.70 20.21 3.53 32.06 19.26 3.89 67 (19.4) 39.74 29.97 2.37 37.83 29.18 2.62 35.81 28.34 2.89 33.68 27.46 3.19 31.38 26.51 3.52 28.99 25.52 3.87
63 (17.2)†† 36.86 28.84 2.36 35.06 28.03 2.61 33.16 27.19 2.88 31.15 26.30 3.18 29.00 25.34 3.51 26.77 24.34 3.86
62 (16.7) 36.35 36.03 2.36 34.75 34.75 2.61 33.22 33.22 2.88 31.57 31.57 3.18 29.78 29.78 3.51 27.89 27.89 3.87 57 (13.9) 36.21 36.21 2.36 34.76 34.76 2.61 33.22 33.22 2.88 31.57 31.57 3.18 29.78 29.78 3.51 27.89 27.89 3.87
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
*FX4CN(B,F)042 1.00 1.00
FE4AN(B,F)003 0.98 0.95 FE4AN(B,F)005 1.01 0.99
FE4ANB006 1.02 0.96
FE4ANF002 0.97 0.98 FF1ENP036 0.97 1.10
FV4BN(B,F)003 0.98 0.95 FV4BN(B,F)005 1.01 0.99
FV4BNB006 1.02 0.96
FV4BNF002 0.97 0.98
FX4CN(B,F)036 0.98 1.00
FY4ANF036 0.97 1.10 FY4ANF042 0.99 1.09
CAP**3614A** 0.96 1.09 CAP**3617A** 0.97 1.10 CAP**3621A** 0.97 1.10 CAP**4221A** 0.98 1.08 CAP**4224A** 0.98 1.08
CNPF*3618A** 0.97 1.10
CNPH*3617A** 0.97 1.10 CNPH*4221A** 0.98 1.09
CNPV*3617A** 0.97 1.10 CNPV*3621A** 0.97 1.10 CNPV*4217A** 0.99 1.09 CNPV*4221A** 0.98 1.09
CSPH*3612A** 0.99 1.05 CSPH*4212A** 1.00 1.06
CAP**3614A** 0.96 1.02 315(A,J)AV036070
CNPH*3617A** 0.96 1.02 315(A,J)AV036070 CNPH*4221A** 0.98 0.99 315(A,J)AV036070
CSPH*3612A** 0.98 1.00 315(A,J)AV036070 CSPH*4212A** 0.99 1.00 315(A,J)AV036070
CAP**3617A** 0.97 0.97 315(A,J)AV048090
CNPH*3617A** 0.97 0.97 315(A,J)AV048090
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
CNPH*4221A** 0.98 0.95 315(A,J)AV048090
CNPV*3617A** 0.97 0.97 315(A,J)AV048090 CNPV*4217A** 0.98 1.00 315(A,J)AV048090
CSPH*3612A** 0.99 0.97 315(A,J)AV048090 CSPH*4212A** 0.99 0.97 315(A,J)AV048090
CAP**3621A** 0.97 0.97 315(A,J)AV060110 CAP**4221A** 0.98 0.98 315(A,J)AV060110
CNPH*3617A** 0.97 0.97 315(A,J)AV060110 CNPH*4221A** 0.98 0.96 315(A,J)AV060110
CNPV*3621A** 0.97 0.97 315(A,J)AV060110 CNPV*4221A** 0.98 0.96 315(A,J)AV060110
CSPH*3612A** 0.99 0.97 315(A,J)AV060110 CSPH*4212A** 0.99 0.97 315(A,J)AV060110
CAP**4224A** 0.98 0.95 315(A,J)AV066135
CNPH*3617A** 0.97 0.97 315(A,J)AV066135 CNPH*4221A** 0.98 0.96 315(A,J)AV066135
CSPH*3612A** 0.99 0.97 315(A,J)AV066135 CSPH*4212A** 0.99 0.97 315(A,J)AV066135
CAP**4224A** 0.98 0.95 315(A,J)AV066155
CNPH*3617A** 0.97 0.97 315(A,J)AV066155 CNPH*4221A** 0.98 0.96 315(A,J)AV066155
CSPH*3612A** 0.99 0.97 315(A,J)AV066155 CSPH*4212A** 1.00 0.98 315(A,J)AV066155
CAP**3617A** 0.97 0.99 353AAV036040
CNPH*3617A** 0.97 0.99 353AAV036040 CNPH*4221A** 0.98 1.00 353AAV036040
CNPV*3617A** 0.97 0.99 353AAV036040 CNPV*4217A** 0.99 1.00 353AAV036040
CSPH*3612A** 0.99 1.01 353AAV036040 CSPH*4212A** 1.01 1.02 353AAV036040
CAP**3617A** 0.98 0.99 353AAV036060
CNPH*3617A** 0.97 0.99 353AAV036060 CNPH*4221A** 0.98 1.00 353AAV036060
CNPV*3617A** 0.97 1.03 353AAV036060
COOLING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
CNPV*4217A** 0.99 1.01 353AAV036060
CSPH*3612A** 1.00 1.02 353AAV036060 CSPH*4212A** 1.01 1.02 353AAV036060
CAP**3617A** 0.97 0.99 353AAV036080
CNPH*3617A** 0.97 0.98 353AAV036080 CNPH*4221A** 0.98 1.00 353AAV036080
CNPV*3617A** 0.97 0.98 353AAV036080 CNPV*4217A** 0.99 1.00 353AAV036080
CSPH*3612A** 0.99 1.01 353AAV036080 CSPH*4212A** 1.00 1.02 353AAV036080
CAP**3617A** 0.98 0.99 353AAV048080
CNPH*3617A** 0.97 0.99 353AAV048080 CNPH*4221A** 0.98 1.00 353AAV048080
CNPV*3617A** 0.97 0.99 353AAV048080 CNPV*4217A** 0.99 1.01 353AAV048080
CSPH*3612A** 0.99 1.01 353AAV048080 CSPH*4212A** 1.01 1.02 353AAV048080
CAP**3621A** 0.98 0.99 353AAV060100 CAP**4221A** 0.98 1.00 353AAV060100
CNPH*3617A** 0.97 0.98 353AAV060100 CNPH*4221A** 0.98 0.99 353AAV060100
CNPV*3621A** 0.97 0.98 353AAV060100 CNPV*4221A** 0.98 0.99 353AAV060100
CSPH*3612A** 0.99 1.01 353AAV060100 CSPH*4212A** 1.00 0.98 353AAV060100
CAP**4224A** 0.97 0.97 355(A,C)AV042040
CNPH*3617A** 0.96 1.02 355(A,C)AV042040 CNPH*4221A** 0.98 0.98 355(A,C)AV042040
CSPH*3612A** 0.98 1.00 355(A,C)AV042040 CSPH*4212A** 0.99 1.00 355(A,C)AV042040
CAP**3617A** 0.97 0.97 355(A,C)AV042060
CNPH*3617A** 0.96 0.98 355(A,C)AV042060 CNPH*4221A** 0.98 0.95 355(A,C)AV042060
