Bryant 225A - Heat Pump Heating Performance; Heating Indoor Capacity and Power

34
HEAT PUMP HEAT ING PERFORMANCE
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES ° F (° C)
--- 3 ( --- 1 9 . 4 ) 7 ( ---13.9) 17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)
EDB
°F (°C)
CFM
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Tota l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* Tot a l Integ* To ta l Integ* To t a l Integ*
225A*A018 ---B Outdoor Section With FX4CNF018 Indoor Section
65
(18.3)
525 6.28 5.77 1.08 8.17 7.51 1.13 10.20 9.30 1.19 12.44 11.05 1.25 14.98 13.63 1.32 17.76 17.76 1.41 20.85 20.85 1.52 24.27 24.27 1.66 600 6.39 5.88 1.08 8.30 7.63 1.13 10.35 9.44 1.17 12.64 11.23 1.23 15.24 13.87 1.29 18.07 18.07 1.37 21.24 21.24 1.47 24.77 24.77 1.60 675 6.49 5.97 1.09 8.41 7.73 1.13 10.48 9.56 1.17 12.81 11.38 1.21 15.44 14.05 1.28 18.32 18.32 1.35 21.54 21.54 1.45 25.12 25.12 1.57
70
(21.1)
525 5.96 5.48 1.13 7.87 7.23 1.19 9.91 9.04 1.24 12.12 10.76 1.30 14.60 13.29 1.38 17.39 17.39 1.47 20.42 20.42 1.59 23.80 23.80 1.73 600 6.07 5.59 1.13 8.01 7.36 1.18 10.07 9.18 1.23 12.32 10.94 1.29 14.89 13.55 1.36 17.70 17.70 1.44 20.82 20.82 1.54 24.29 24.29 1.67 675 6.17 5.68 1.13 8.12 7.46 1.18 10.20 9.30 1.22 12.49 11.09 1.27 15.09 13.73 1.34 17.94 17.94 1.41 21.12 21.12 1.51 24.65 24.65 1.63
75
(23.9)
525 5.62 5.17 1.17 7.56 6.95 1.24 9.61 8.76 1.30 11.82 10.50 1.37 14.26 12.97 1.45 17.02 17.02 1.54 20.00 20.00 1.66 23.34 23.34 1.80 600 5.73 5.27 1.18 7.70 7.07 1.23 9.77 8.91 1.29 12.01 10.66 1.35 14.50 13.20 1.42 17.32 17.32 1.51 20.39 20.39 1.61 23.82 23.82 1.74 675 5.83 5.36 1.18 7.81 7.18 1.23 9.91 9.03 1.28 12.16 10.80 1.33 14.72 13.39 1.40 17.57 17.57 1.48 20.69 20.69 1.58 24.18 24.18 1.70
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
*FX4CNF018 1.00 1.00
FE4ANF002 0.99 0.97 FF1ENP018 1.02 1.08 FF1ENP024 1.02 1.06 FV4BNF002 0.99 0.97
FX4CNF024 1.00 0.99
FY4ANF018 1.02 1.09 FY4ANF024 1.02 1.08
CNPF*2418A** 1.02 1.04
CNPH*2417A** 1.02 1.04
CNPV*2414A** 1.02 1.04 CNPV*2417A** 1.02 1.04
CSPH*2412A** 1.02 1.04
CAP**2414A** 0.98 1.01 315(A,J)AV036070
CNPH*2417A** 0.98 1.00 315(A,J)AV036070
CNPV*2414A** 0.98 1.00 315(A,J)AV036070
CSPH*2412A** 0.98 1.00 315(A,J)AV036070
CAP**2417A** 0.98 1.00 315(A,J)AV048090
CNPH*2417A** 0.99 1.00 315(A,J)AV048090
CNPV*2417A** 0.99 1.00 315(A,J)AV048090
CSPH*2412A** 0.99 1.00 315(A,J)AV048090
CAP**2417A** 1.01 0.95 353AAV036040
CNPH*2417A** 1.01 0.96 353AAV036040
CNPV*2417A** 1.01 0.96 353AAV036040
CSPH*2412A** 1.00 0.97 353AAV036040
CAP**2417A** 1.00 0.97 353AAV036060
CNPH*2417A** 0.99 0.97 353AAV036060
CNPV*2417A** 0.99 0.97 353AAV036060
CSPH*2412A** 0.98 0.99 353AAV036060
CNPH*2417A** 0.99 1.00 355(A,C)AV042040
CSPH*2412A** 0.98 1.00 355(A,C)AV042040
CAP**2417A** 0.98 1.01 355(A,C)AV042060
CNPH*2417A** 0.98 0.99 355(A,C)AV042060
CNPV*2417A** 0.99 1.00 355(A,C)AV042060
CSPH*2412A** 0.99 1.00 355(A,C)AV042060
CNPH*2417A** 0.99 1.00 355(A,C)AV042080
CSPH*2412A** 0.99 1.00 355(A,C)AV042080
CAP**1814A** 0.98 1.02 313*AV024045 CAP**2414A** 1.00 0.99 313*AV024045
CNPH*2417A** 1.00 0.98 313*AV024045
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
CNPV*1814A** 0.99 1.01 313*AV024045 CNPV*2414A** 1.00 0.98 313*AV024045
CSPH*2412A** 1.00 0.99 313*AV024045
Seenoteonpg.33
