43
HEAT PUMP HEATING PERFORMANCE CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES ° F (° C)
--- 3 ( --- 1 9 . 4 ) 7 ( ---13.9) 17 ( ---8.3) 27 ( ---2.8) 37 (2.8) 47 (8.3) 57 (13.9) 67 (19.4)
EDB
°F (°C)
CFM
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Capacity MBtuh
Tota l
Sys.
KW†
Tota l Integ* To t a l Integ* To t a l Integ* To t a l Integ* To t a l Integ* Tot a l Integ* To ta l Integ* To t a l Integ*
225A*A060 ---B Outdoor Section With FX4CN(B,F)060 Indoor Section
65
(18.3)
1750 23.48 21.60 3.26 29.16 26.80 3.39 35.23 32.12 3.53 41.70 37.04 3.70 48.76 44.37 3.88 57.02 57.02 4.12 66.63 66.63 4.35 76.53 76.53 4.64
2000 23.94 22.03 3.31 29.66 27.26 3.42 35.77 32.61 3.55 42.29 37.56 3.70 49.47 45.02 3.86 57.90 57.90 4.08 67.49 67.49 4.27 77.13 77.13 4.53
2250 24.37 22.42 3.36 30.11 27.67 3.47 36.24 33.05 3.59 42.81 38.02 3.72 50.12 45.61 3.87 58.69 58.69 4.06 67.98 67.98 4.24 77.31 77.31 4.47
70
(21.1)
1750 22.72 20.90 3.41 28.46 26.15 3.55 34.56 31.51 3.71 41.06 36.46 3.88 48.05 43.73 4.07 56.15 56.15 4.31 65.57 65.57 4.57 75.53 75.53 4.86
2000 23.18 21.33 3.46 28.97 26.62 3.59 35.11 32.01 3.72 41.66 37.00 3.88 48.74 44.35 4.05 57.00 57.00 4.27 66.59 66.59 4.48 76.22 76.22 4.75
2250 23.61 21.72 3.52 29.43 27.04 3.63 35.60 32.46 3.76 42.18 37.46 3.90 49.33 44.89 4.06 57.73 57.73 4.26 67.16 67.16 4.44 76.51 76.51 4.68
75
(23.9)
1750 21.89 20.14 3.56 27.70 25.46 3.72 33.86 30.87 3.89 40.39 35.87 4.07 47.50 43.23 4.28 55.05 55.05 4.51 64.53 64.53 4.79 74.52 74.52 5.09
2000 22.37 20.58 3.61 28.22 25.93 3.76 34.42 31.38 3.90 40.99 36.40 4.07 48.02 43.70 4.25 55.99 55.99 4.47 65.60 65.60 4.69 75.29 75.29 4.97
2250 22.80 20.98 3.67 28.68 26.36 3.80 34.91 31.83 3.94 41.52 36.88 4.09 48.61 44.24 4.25 56.84 56.84 4.46 66.32 66.32 4.65 75.63 75.63 4.90
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
*FX4CN(B,F)060 1.00 1.00
FE4ANB006 1.00 1.00
FV4BNB006 1.00 1.00
FY4ANB060 1.02 1.07
CAP**6021A** 1.01 1.06
CAP**6024A** 1.01 1.06
CNPH*6024A** 1.01 1.07
CNPV*6024A** 1.01 1.07
CSPH*6012A** 1.01 1.05
CAP**6021A** 1.00 1.05 315(A,J)AV060110
CNPH*6024A** 1.00 1.06 315(A,J)AV060110
CSPH*6012A** 1.01 1.05 315(A,J)AV060110
CAP**6024A** 1.00 1.04 315(A,J)AV066135
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
CNPH*6024A** 1.00 1.05 315(A,J)AV066135
CNPV*6024A** 1.00 1.05 315(A,J)AV066135
CSPH*6012A** 1.00 1.03 315(A,J)AV066135
CAP**6024A** 1.00 1.03 315(A,J)AV066155
CNPH*6024A** 1.00 1.04 315(A,J)AV066155
CNPV*6024A** 1.00 1.04 315(A,J)AV066155
CSPH*6012A** 1.00 1.02 315(A,J)AV066155
CNPH*6024A** 1.00 1.08 353AAV048080
CSPH*6012A** 1.00 1.06 353AAV048080
CAP**6021A** 1.00 1.05 353AAV060100
CNPH*6024A** 0.99 1.05 353AAV060100
CSPH*6012A** 1.00 1.04 353AAV060100
CAP**6024A** 0.99 1.04 353AAV060120
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MO DEL
CNPH*6024A** 0.99 1.04 353AAV060120
CNPV*6024A** 0.99 1.04 353AAV060120
CSPH*6012A** 1.00 1.03 353AAV060120
CAP**6021A** 1.00 1.06 313*AV048090
CNPH*6024A** 1.00 1.06 313*AV048090
CSPH*6012A** 1.00 1.04 313*AV048090
CAP**6021A** 1.00 1.04 313*AV060110
CNPH*6024A** 1.00 1.04 313*AV060110
CSPH*6012A** 1.00 1.03 313*AV060110
CAP**6024A** 1.00 1.05 313*AV060135
CNPH*6024A** 1.00 1.05 313*AV060135
CNPV*6024A** 1.00 1.05 313*AV060135
CSPH*6012A** 1.00 1.04 313*AV060135
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* The Btuh heating capacity values shown are net integrated values from which the defrost effect has been subtracted. The Btuh heating from supplement heaters should be added to those values to obtain total system capacity.
{ The kW values include the compressor, outdoor fan motor, and indoor blower motor. The kW from supplement heaters should be added to these values to obtain total system kilowatts.
EDB —EnteringDryBulb
225A
