TABLE 9—MODEL 340MAV ORIFICE SIZE AND MANIFOLD PRESSURE FOR CORRECT INPUT (Continued)
FOR USE WITH 040 THROUGH 120 SIZE FURNACES ONLY
(TABULATED DATA BASED ON 20,000 BTUH PER BURNER, DERATED 2% FOR EACH 1000 FT ABOVE SEA LEVEL)
ALTITUDE
RANGE
(FT)
AVG GAS
HEAT VALUE
AT ALTITUDE
(BTU/CU FT)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64 0.66
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
U.S.A. Only
625 43 3.8 42 3.3 42 3.4 42 3.5 42 3.6
650 43 3.5 43 3.7 43 3.8 42 3.2 42 3.3
7001 675 44 3.8 43 3.4 43 3.5 43 3.6 43 3.7
700 44 3.5 44 3.6 44 3.8 43 3.4 43 3.5
to 725 44 3.3 44 3.4 44 3.5 44 3.6 44 3.7
750 45 3.7 45 3.8 44 3.3 44 3.4 44 3.5
8000 775 45 3.5 45 3.6 45 3.7 45 3.8 44 3.3
800 45 3.3 45 3.4 45 3.5 45 3.6 45 3.7
15% 825 45 3.1 45 3.2 45 3.3 45 3.4 45 3.5
derate 850 45 2.9 45 3.0 45 3.1 45 3.2 45 3.3
ALTITUDE
RANGE
(FT)
AVG GAS
HEAT VALUE
AT ALTITUDE
(BTU/CU FT)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64 0.66
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
U.S.A. Only
600 43 3.8 42 3.3 42 3.4 42 3.5 42 3.6
8001 625 43 3.5 43 3.6 43 3.8 42 3.2 42 3.3
650 44 3.7 43 3.4 43 3.5 43 3.6 43 3.7
to 675 44 3.5 44 3.6 44 3.7 44 3.8 43 3.4
700 44 3.2 44 3.3 44 3.4 44 3.6 44 3.7
9000 725 45 3.6 45 3.8 44 3.2 44 3.3 44 3.4
750 45 3.4 45 3.5 45 3.6 45 3.8 44 3.2
17% 775 45 3.2 45 3.3 45 3.4 45 3.5 45 3.6
derate 800 45 3.0 45 3.1 45 3.2 45 3.3 45 3.4
ALTITUDE
RANGE
(FT)
AVG GAS
HEAT VALUE
AT ALTITUDE
(BTU/CU FT)
SPECIFIC GRAVITY OF NATURAL GAS
0.58 0.60 0.62 0.64 0.66
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
Orifice
No.
Manifold
Pressure
U.S.A. Only
575 43 3.8 42 3.2 42 3.3 42 3.5 42 3.6
9001 600 43 3.5 43 3.6 43 3.7 42 3.2 42 3.3
625 44 3.7 44 3.8 43 3.5 43 3.6 43 3.7
to 650 44 3.4 44 3.5 44 3.7 44 3.8 43 3.4
675 45 3.8 44 3.3 44 3.4 44 3.5 44 3.6
10,000 700 45 3.6 45 3.7 45 3.8 44 3.3 44 3.4
725 45 3.3 45 3.4 45 3.6 45 3.7 45 3.8
19% 750 45 3.1 45 3.2 45 3.3 45 3.4 45 3.5
derate 775 45 2.9 45 3.0 45 3.1 45 3.2 45 3.3
*Orifice numbers shown in BOLD are factory installed.
Percents of derate are based on midpoints of U.S. altitude ranges.
