Bryant 558D - Page 20

GROSS COOLING CAPACITIES (cont)
558D090 (7
1
⁄ 2 TON)
Air Entering
Evaporator
Air Entering Condenser (F)
75 85 95
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible Total Sensible
2250 0.07
72 102.8 49.4 7.14 98.6 48.0 7.66 93.8 46.4 8.18
67 94.8 61.8 6.82 90.2 60.2 7.34 85.2 58.2 7.84
62 86.2 73.2 6.50 81.6 71.2 7.00 76.6 68.8 7.48
2800 0.09
72 105.8 52.6 7.28 101.8 51.6 7.82 97.0 50.2 8.36
67 98.2 67.8 6.98 93.6 66.4 7.50 88.4 64.6 8.00
62 90.0 81.6 6.68 85.2 79.6 7.18 80.0 77.2 7.64
3000 0.10
72 106.4 53.6 7.32 102.6 52.8 7.86 97.6 51.4 8.40
67 99.0 69.8 7.04 94.4 68.6 7.54 89.0 66.8 8.04
62 90.8 84.0 6.72 86.0 82.0 7.22 81.2 79.0 7.70
3750 0.12
72 109.2 58.2 7.46 104.6 56.8 7.98 99.4 55.6 8.50
67 101.6 77.4 7.18 96.8 76.0 7.68 91.2 74.4 8.16
62 93.6 92.2 6.86 89.6 89.4 7.40 85.2 85.2 7.92
558D090 (7
1
⁄ 2 TON) (cont)
Air Entering
Evaporator
Air Entering Condenser (F)
105 115
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible
2250 0.07
72 88.4 44.6 8.68 82.8 42.6 9.16
67 79.8 56.2 8.30 73.8 53.8 8.78
62 70.8 66.0 7.98 66.0 63.2 8.42
2800 0.09
72 91.0 48.2 8.80 85.2 46.4 9.30
67 82.8 62.6 8.46 76.8 60.4 8.92
62 74.6 74.2 8.14 69.6 69.6 8.64
3000 0.10
72 91.6 49.4 8.86 85.6 47.8 9.34
67 83.4 64.8 8.50 77.4 62.6 8.96
62 76.0 75.6 8.20 71.0 71.0 8.72
3750 0.12
72 93.8 54.2 8.98 87.6 52.8 9.48
67 85.4 72.4 8.64 79.4 70.4 9.10
62 80.6 80.6 8.42 76.0 75.8 8.94
558D102 (8
1
⁄ 2 TON)
Air Entering
Evaporator
Air Entering Condenser (F)
75 85 95
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible Total Sensible
2550 0.080
72 116.6 71.9 7.77 113.3 54.0 8.46 109.1 77.4 8.90
67 108.4 61.9 7.57 104.2 67.7 8.22 99.3 65.9 8.97
62 99.0 75.9 7.38 94.0 80.4 7.96 87.3 52.6 8.68
3000 0.10
72 119.2 75.2 7.86 115.7 56.3 5.54 111.2 55.0 8.99
67 111.3 65.1 10.68 106.9 72.5 8.31 102.0 70.9 9.06
62 101.8 81.4 7.44 97.0 87.1 8.04 91.4 84.9 8.79
3400 0.110
72 120.1 80.5 7.89 117.2 58.2 8.60 112.5 57.1 9.06
67 112.8 68.0 6.72 108.7 76.4 8.38 103.6 75.1 9.12
62 103.6 85.6 7.51 98.8 92.5 8.12 93.7 90.3 8.86
4250 0.135
72 122.3 32.7 7.97 120.1 62.9 8.72 115.3 62.2 4.76
67 114.8 73.9 7.80 111.0 84.2 8.48 105.8 83.2 9.24
62 106.3 94.4 7.60 101.8 101.0 8.23 107.4 97.3 9.00
558D102 (8
1
⁄ 2 TON) (cont)
Air Entering
Evaporator
Air Entering Condenser (F)
105 115
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible
2550 0.080
72 103.3 50.5 9.74 97.7 48.7 10.33
67 94.0 54.0 9.43 87.9 61.7 9.97
62 81.4 74.5 9.08 75.9 71.9 9.61
3000 0.10
72 105.9 53.5 9.85 99.9 51.8 10.46
67 96.3 69.1 9.54 90.4 66.9 10.10
62 84.6 81.4 9.21 78.8 78.1 9.75
3400 0.110
72 107.4 55.8 9.92 101.3 54.0 10.54
67 97.7 73.1 9.60 91.8 71.2 10.18
62 87.9 86.6 9.29 82.4 82.3 9.88
4250 0.135
72 109.4 60.4 10.03 102.9 58.5 10.61
67 99.9 81.4 9.72 93.8 79.4 10.30
62 92.8 92.8 9.48 88.3 88.2 10.10
(See Legend and Notes on page 18.)
