Bryant 558D - Page 21

GROSS COOLING CAPACITIES (cont)
558D120 (10 TON)
Air Entering
Evaporator
Air Entering Condenser (F)
75 85 95
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible Total Sensible
3000 0.095
72 135.8 66.8 9.76 130.0 64.3 10.41 124.1 62.2 11.13
67 124.8 82.6 9.41 119.6 80.5 10.07 113.7 78.4 10.78
62 112.0 97.4 9.10 104.0 93.8 9.74 96.7 90.0 10.40
4000 0.125
72 142.4 73.2 10.00 136.0 71.1 10.67 129.5 69.1 11.38
67 130.6 93.4 9.61 125.0 91.7 10.28 118.9 89.8 10.99
62 119.8 112.7 9.27 114.5 110.2 9.94 106.9 105.9 10.63
5000 0.150
72 146.5 79.7 10.17 140.0 77.5 10.84 132.8 74.9 11.52
67 134.2 104.4 9.75 127.9 101.8 10.41 122.0 100.1 11.14
62 123.7 123.1 9.41 118.8 118.7 10.09 114.1 114.0 10.83
558D120 (10 TON) (cont)
Air Entering
Evaporator
Air Entering Condenser (F)
105 115
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible
3000 0.095
72 118.1 60.4 11.93 115.0 59.4 12.26
67 104.6 74.9 11.52 98.0 72.4 11.82
62 87.9 85.2 11.10 84.2 83.4 11.40
4000 0.125
72 122.7 66.9 12.13 120.0 66.4 12.48
67 111.8 87.7 11.74 103.8 84.8 12.06
62 98.5 98.5 11.41 93.4 93.4 11.78
5000 0.150
72 126.0 73.1 12.27 122.6 72.8 12.60
67 115.1 98.3 11.89 109.8 96.6 12.20
62 108.0 108.0 11.65 102.8 102.8 12.00
558D150 (12
1
⁄ 2 TON)
Air Entering
Evaporator
Air Entering Condenser (F)
75 85 95
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible Total Sensible
3750 0.08
72 175.6 85.7 11.16 169.3 83.9 12.15 161.9 81.4 13.12
67 162.2 107.3 10.85 155.7 104.8 11.78 148.9 102.0 12.72
62 149.2 128.0 10.57 140.6 124.0 11.42 132.0 119.8 12.28
4500 0.09
72 181.0 91.4 11.32 174.2 89.6 12.31 166.8 87.0 13.30
67 167.5 116.2 11.00 160.7 113.9 11.94 153.5 111.1 12.89
62 154.2 140.3 10.69 147.0 137.0 11.58 139.1 133.2 12.46
5000 0.10
72 182.9 94.2 11.37 176.9 92.7 12.39 169.5 90.7 13.40
67 170.2 122.2 11.07 163.0 119.7 12.01 155.7 117.3 12.97
62 156.4 146.5 10.73 149.7 143.6 11.63 142.8 140.2 12.56
6250 0.12
72 187.2 102.1 11.49 181.5 100.9 12.52 173.2 98.3 13.54
67 174.7 135.3 11.19 167.3 133.4 12.14 159.5 130.8 13.11
62 161.8 160.7 10.87 155.8 155.6 11.82 149.6 149.6 12.78
558D150 (12
1
⁄ 2 TON) (cont)
Air Entering
Evaporator
Air Entering Condenser (F)
105 115
Cfm BF
Ewb
(F)
Capacity MBtuh
Compressor
kW
Capacity MBtuh
Compressor
kW
Total Sensible Total Sensible
3750 0.08
72 154.9 79.0 14.16 146.2 76.1 15.09
67 141.3 99.2 13.66 132.2 95.7 14.57
62 123.0 115.5 13.17 113.1 110.3 14.07
4500 0.09
72 158.8 84.5 14.31 150.5 81.7 15.30
67 145.4 108.2 13.82 137.0 105.2 14.76
62 130.2 128.1 13.35 122.4 122.3 14.25
5000 0.10
72 160.9 87.8 14.38 152.3 85.0 15.37
67 147.6 114.3 13.91 139.4 111.6 14.87
62 135.0 134.9 13.48 127.8 127.7 14.43
6250 0.12
72 165.3 96.6 14.58 155.2 92.9 15.49
67 151.2 127.8 14.07 142.7 125.0 15.02
62 143.2 143.1 13.77 136.0 135.8 14.73
(See Legend and Notes on page 22.)
21
