Bryant 577C Installation Instructions

22
Table 8 – Filter Pr essur e Drop Table (IN. W.C.)
FILTER SIZE
in. (mm)
CFM
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000 2100 2200 2300
20X20X1
(508X508X25)
0.05 0.07 0.08 0.1 0.12 0.13 0.14 0.15 — — — — — — — — — — —
20X24X1
(508X610x25)
— — — — 0.09 0.10 0.11 0.13 0.14 0.15 0.16 — — — — — — — —
24X30X1
(610X762x25)
— — — 0.04 0.05 0.06 0.07 0.07 0.08 0.09 0.1 — — — — — — — —
24X36X1
(610X914X25)
— — — — — — — 0.06 0.07 0.07 0.08 0.09 0.09 0.10 0.11 0.12 0.13 0.14 0.14
Table 9 – Dry Coil Air Delivery* -- Horizontal and Downflow Discharge --
Unit 577C018 --060
UNIT
HEATING
RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (”WC)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9
577C018040
30 --- 60
o
F
( 1 7 --- 3 3
o
C)
Low
2
Blue
CFM 785 652 508 --- --- --- --- --- --- --- --- --- --- --- ---
Heating Rise
(
o
F)
38 46 59 NA NA NA NA NA NA
Heating Rise
(
o
C)
21 26 33 NA NA NA NA NA NA
M e d ---
Low
Pink
CFM 793 665 545 --- --- --- --- --- --- --- --- --- --- --- ---
Heating Rise
(
o
F)
38 45 55 NA NA NA NA NA NA
Heating Rise
(
o
C)
21 25 31 NA NA NA NA NA NA
Medium Red
CFM 838 745 645 542 --- --- --- --- --- --- --- --- --- ---
Heating Rise
(
o
F)
36 41 47 56 NA NA NA NA NA
Heating Rise
(
o
C)
20 23 26 31 NA NA NA NA NA
M e d ---
High
1
Orange
CFM 842 749 658 589 487 --- --- --- --- --- --- --- ---
Heating Rise
(
o
F)
36 40 46 51 NA NA NA NA NA
Heating Rise
(
o
C)
20 22 26 29 NA NA NA NA NA
High Black
CFM 1124 1047 976 898 822 749 656 --- --- --- ---
Heating Rise
(
o
F)
NA NA 31 34 37 40 46 NA NA
Heating Rise
(
o
C)
NA NA 17 19 20 22 26 NA NA
577C024040
30 --- 60
o
F
( 1 7 --- 3 3
o
C)
Low Blue
CFM 741 638 547 415 --- --- --- --- --- --- --- --- --- ---
Heating Rise
(
o
F)
41 47 55 NA NA NA NA NA NA
Heating Rise
(
o
C)
23 26 31 NA NA NA NA NA NA
M e d ---
Low
2
Pink
CFM 898 820 738 662 536 --- --- --- --- --- --- --- ---
Heating Rise
(
o
F)
34 37 41 46 56 NA NA NA NA
Heating Rise
(
o
C)
19 20 23 25 31 NA NA NA NA
Medium
1
Red
CFM 973 887 823 733 665 538 451 --- --- --- ---
Heating Rise
(
o
F)
31 34 37 41 45 56 NA NA NA
Heating Rise
(
o
C)
17 19 20 23 25 31 NA NA NA
M e d ---
High
Orange
CFM 1140 1064 996 915 840 758 687 564 480
Heating Rise
(
o
F)
NA NA 30 33 36 40 44 54 NA
Heating Rise
(
o
C)
NA NA 17 18 20 22 24 30 NA
High Black
CFM 1202 1140 1082 1015 961 881 810 732 631
Heating Rise
(
o
F)
NA NA NA 30 31 34 37 41 48
Heating Rise
(
o
C)
NA NA NA 17 17 19 21 23 27
