Table 14 – Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- 208/230 VAC 3--Phase Models
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
24040
15 - 45
o
FLowStage,
20 - 50
o
FHighStage
Low
3
Blue
CFM 714 525 --- --- --- --- --- --- --- --- BHP 0.08 0.07 --- --- --- --- --- --- --- --- Low Stage Heat Rise
o
F
(
o
C)
26
(15)
36
(20)
NA NA NA NA NA NA NA NA
High Stage Heat R ise
o
F
(
o
C)
41
(23)
NA NA NA NA NA NA NA NA NA
Med-Low
1
Pink
CFM 689 597 489 352 --- --- --- --- --- --- BHP 0.08 0.06 0.06 0.05 --- --- --- --- --- --- Low Stage Heat Rise
o
F
(
o
C)
27
(15)
31
(17)
38
(21)
NA NA NA NA NA NA NA
High Stage Heat R ise
o
F
(
o
C)
42
(23)
49
(27)
NA NA NA NA NA NA NA NA
Medium
4
Red
CFM 877 779 698 598 519 410 --- --- --- --- BHP 0.12 0.12 0.13 0.14 0.15 0.15 --- --- --- --- Low Stage Heat Rise
o
F
(
o
C)
21
(12)
24
(13)
27
(15)
31
(17)
36
(20)
NA NA NA NA NA
High Stage Heat R ise
o
F
(
o
C)
33
(18)
37
(21)
42
(23)
49
(27)
NA NA NA NA NA NA
Med-High
2
Orange
CFM 921 829 754 663 582 485 371 --- --- --- BHP 0.14 0.14 0.15 0.16 0.17 0.17 0.18 --- --- --- Low Stage Heat Rise
o
F
(
o
C)
20
(11)
23
(13)
25
(14)
28
(16)
32
(18)
39
(22)
NA NA NA NA
High Stage Heat R ise
o
F
(
o
C)
32
(18)
35
(20)
39
(21)
44
(24)
50
(28)
NA NA NA NA NA
High Black
CFM 1291 1206 1142 1081 1017 951 888 823 753 668 BHP 0.31 0.32 0.33 0.34 0.34 0.35 0.36 0.36 0.37 0.37 Low Stage Heat Rise
o
F
(
o
C)
15
(8)
16
(9)
16
(9)
17
(10)
18
(10)
20
(11)
21
(12)
23
(13)
25
(14)
28
(16)
High Stage Heat R ise
o
F
(
o
C)
23
(13)
24
(13)
25
(14)
27
(15)
29
(16)
31
(17)
33
(18)
35
(20)
39
(21)
44
(24)
