ARI* CAPACITY RATINGS — 580F036-151
LEGEND
*Air Conditioning and Refrigeration Institute.
†Applies only to units with capacity of 65,000 Btuh or less.
**The IPLV applies only to two-stage cooling units.
NOTES:
1. Rated in accordance with ARI Standards 210/240 (for sizes 036-
120) or 360, (for size 150 and 151) and 270.
2. ARI ratings are net values, reflecting the effects of circulating fan
heat.
3. Ratings are based on:
Cooling Standard: 80 F db, 67 F wb indoor entering-air tempera-
ture and 95 F db air entering outdoor unit.
IPLV Standard: 80 F db, 67 F wb indoor entering-air temperature
and 80 F db outdoor entering-air temperature.
4. All 580F036, 048, 060, 073, 091, 103, 121, 151 units are in com-
pliance with ASHRAE 90.1-1999 Energy Standard for minimum
SEER and EER requirements. Refer to state and local codes or
visit the following website: http://bcap-energy.org
to determine if
compliance with this standard pertains to a given geographical
area of the United States.
HEATING CAPACITIES AND EFFICIENCIES (Standard-Efficiency Units) — 580F036-151
208/230-1-60 — SINGLE-STAGE GAS HEAT
208/230-1-60 — SINGLE-STAGE GAS HEAT — LOW NOx
UNIT 580F
NOMINAL
TONS
STANDARD
CFM
NET COOLING
CAPACITY
(Btuh)
TOTAL
kW
SEER† SOUND
RATING
(dB)
Belt Drive Direct Drive
036 3 1200 35,000 4.0 10.0 9.7 81
048 4 1600 47,000 5.3 10.0 9.7 81
060 5 2000 57,000 6.7 10.0 9.7 81
UNIT
580F
NOMINAL
TONS
NET COOLING
CAPACITY
(Btuh)
TOTAL
kW
EER
SOUND
RATING
(dB)
IPLV
072 6 72,000 8.0 9.0 81 **
073 6 71,000 7.0 10.1 80 **
090
7
1
/
2
85,000 9.6 8.9 87 9.40
091
7
1
/
2
88,000 8.7 10.1 82 10.5
103
8
1
/
2
100,000 9.9 10.1 82 10.4
120 10 117,000 13.0 9.0 88 9.40
121 10 114,000 11.3 10.1 84 11.0
150
12
1
/
2
144,000 16.0 9.0 87 9.20
151
12
1
/
2
136,000 14.3 9.5 86 9.70
dB — Sound Levels (decibels)
db — Dry Bulb
EER — Energy Efficiency Ratio
IPLV — Integrated Part-Load Values
SEER — Seasonal Energy Efficiency Ratio
wb — Wet Bulb
UNIT
580F
INPUT
CAPACITY
OUTPUT
CAPACITY
TEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
AFUE (%) Steady State (%)
036074 74,000 57,000 25-55 1004 80 80
036115 115,000 89,000 55-85 1002 80 80
048074 74,000 57,000 25-55 1004 80 80
048115 115,000 91,000 35-65 1327 80 80
048150 150,000 118,000 50-80 1396 80 80
060074 74,000 57,000 25-55 1004 80 80
060115 115,000 91,000 35-65 1327 80 80
060150 150,000 118,000 50-80 1314 80 80
UNIT
580F
INPUT
CAPACITY
OUTPUT
CAPACITY
TEMPERATURE
RISE (°F)
MINIMUM HEATING
AIRFLOW (CFM)
EFFICIENCY
AFUE (%) Steady State (%)
036060N 60,000 49,000 20-50 910 80 80
036090N 90,000 73,000 30-60 1130 80 80
048060N 60,000 49,000 20-50 910 80 80
048090N 90,000 73,000 30-60 1130 80 80
048120N 120,000 98,000 40-70 1300 80 80
060060N 60,000 49,000 20-50 910 80 80
060090N 90,000 73,000 30-60 1130 80 80
060120N 120,000 98,000 40-70 1300 80 80
