Bryant 579F - Page 136

136
PERFORMANCE DATA (cont)
POWER EXHAUST OPTIONS
*Single or three phase rooftop unit.
POWER EXHAUST POWER REQUIREMENTS
LEGEND
MOCP — Maximum Overcurrent Protection
VERTICAL — MOUNTED IN ECONOMIZER HOOD
POWER EXHAUST
PART NO.
POWER EXHAUST DESCRIPTION
APPLICATION
USAGE
POWER OUTPUT
(Hp per fan)
NO.
FANS
CRPWREXH030A01 Power Exhaust System (208/230-1-60) 036-072* 0.23 2
CRPWREXH021A01 Power Exhaust System (460-3-60) 036-072 0.24 2
CRPWREXH022A01 Power Exhaust System (208/230-1-60) 090-150* 0.47 2
CRPWREXH023A01 Power Exhaust System (460-3-60) 090-150 0.37 2
HORIZONTAL — MOUNTED IN RETURN DUCTWORK
POWER EXHAUST|
PART NO.
POWER EXHAUST DESCRIPTION
APPLICATION
USAGE
POWER OUTPUT
(Hp per fan)
NO.
FANS
CRPWREXH028A01 Horizontal Power Exhaust (208/230-1-60) All* 0.48 1
CRPWREXH029A01 Horizontal Power Exhaust (460-3-60) All 0.48 1
POWER EXHAUST
SIZE
AMPS AT 230 V
(2 FANS RUNNING)
MOCP
230 VAC 460 VAC 575 VAC
3 to 6 Ton
1.40 amps
at 60 Hz
15.0
amps
15.0
amps
15.0
amps
7
1
/
2
to 12
1
/
2
Ton
3.04 amps
at 60 Hz
581B036-150
