162
EVAPORATOR-FAN MOTOR EFFICIENCY —
581C024-060
*Single phase/3 phase.
NOTES:
1. Convert bhp to watts using the following formula:
2. The EPACT (Energy Policy Act of 1992) regulates energy require-
ments for specific types of indoor fan motors. Motors regulated by
EPACT include any general purpose, T-frame (three-digit, 143 and
larger), single-speed, foot mounted, polyphase, squirrel cage
induction motors of NEMA (National Electrical Manufacturers
Association) design A and B, manufactured for use in the United
States. Ranging from 1 to 200 Hp, these continuous-duty motors
operate on 230 and 460 volt, 60 Hz power. If a motor does not fit
into these specifications, the motor does not have to be replaced
by an EPACT-compliant energy-efficient motor. Variable-speed
motors are exempt from EPACT compliance requirements. There-
fore, the indoor fan motors for Bryant 581C024-060 units are
exempt from these requirements.
ACCESSORY/FIOP STATIC PRESSURE* (in. wg) — 581C024-060
LEGEND *The static pressure must be added to external static pressure. The
sum and the evaporator entering-air cfm should be used in conjunction
with the Fan Performance tables to determine indoor blower rpm and
watts.
581C - OPTION/ACCESSORY WEIGHTS
UNIT SIZE
581C
EFFICIENCY%
024, 036, 048 75
060 74/84*
watts =
bhp (746)
motor efficiency
COMPONENT
CFM
600 800 1000 1250 1500 1750 2000 2250 2500 2750
3000
Vertical EconoMi$er IV and EconoMi$er2 0.10 0.20 0.35 0.045 0.065 0.08 0.12 0.145 0.175 0.22
0.255
Horizontal EconoMi$er IV and EconoMi$er2 — — — — — 0.1 0.125 0.15 0.18 0.225
0.275
FIOP — Factory-Installed Option
Option / Accessory
024 036 048 060
lb kg lb kg lb kg lb kg
Perfect Humidity Dehumidification System 13 6 15 7 23 10 25 11
Power Exhaust - vertical 50 23 50 23 50 23 50 23
Power Exhaust - horizontal 30 14 30 14 30 14 30 14
EconoMi$er ( IV or 2) 50 23 50 23 50 23 50 23
Two Position damper (25%) 22 10 22 10 22 10 22 10
Two Position damper (100%) 39 18 39 18 39 18 39 18
Manual Dampers 12 5 12 5 12 5 12 5
Hail Guard (louvered) 16 7 16 7 16 7 16 7
Hail Guard (standard hood assembly) 25 11 25 11 25 11 25 11
Cu/Cu Condenser Coil 5263136136
Cu/Cu Condenser and Evaporator Coils 10 5 12 5 19 9 21 10
Roof Curb (14-in. curb) 115 52 115 52 115 52 115 52
Roof Curb (24-in. curb) 197 89 197 89 197 89 197 89
581C024-060
