—20—
CONDENSER ONLY RATINGS* Continued
* ARI listing applies only to systems shown in Performance Data table.
KW — Total Power (Kw)
SDT — Saturated Temperature Leaving Compressor (°F)
SST — Saturated Temperature Entering Compressor (°F)
TCG — Gross Cooling Capacity (1000 Btuh)
SST
°F
CONDENSER ENTERING AIR TEMPERATURES °F
55 65 75 85 95 105 115
594D042-E
30
TCG 39.4 37.6 35.7 33.9 32.0 30.2 28.4
SDT 77.0 86.9 96.8 107.0 117.0 127.0 137.0
KW 2.17 2.43 2.72 3.04 3.40 3.81 4.26
35
TCG 43.3 41.4 39.4 37.4 35.4 33.4 31.4
SDT 78.5 88.2 98.0 108.0 118.0 128.0 138.0
KW 2.19 2.45 2.74 3.07 3.43 3.84 4.30
40
TCG 47.5 45.4 43.3 41.1 39.0 36.8 34.6
SDT 80.0 89.7 99.5 109.0 119.0 129.0 139.0
KW 2.21 2.48 2.77 3.10 3.47 3.88 4.34
45
TCG 51.8 49.6 47.4 45.1 42.7 40.4 38.1
SDT 81.7 91.4 101.0 111.0 121.0 131.0 141.0
KW 2.24 2.51 2.80 3.14 3.51 3.92 4.39
50
TCG 56.4 54.1 51.7 49.2 46.7 44.2 41.7
SDT 83.6 93.2 103.0 113.0 122.0 132.0 142.0
KW 2.27 2.54 2.84 3.18 3.55 3.97 4.44
55
TCG 61.2 58.8 56.2 53.6 51.0 48.3 45.6
SDT 85.6 95.1 105.0 114.0 124.0 134.0 144.0
KW 2.31 2.58 2.88 3.22 3.60 4.03 4.50
594D048-E, F
30
TCG 46.0 43.8 41.6 39.3 36.9 34.4 32.0
SDT 80.1 89.8 99.6 109.0 119.0 129.0 139.0
KW 2.46 2.82 3.22 3.65 4.13 4.64 5.17
35
TCG 50.4 48.1 45.7 43.2 40.7 38.1 35.5
SDT 81.9 91.6 101.0 111.0 121.0 131.0 140.0
KW 2.49 2.85 3.25 3.69 4.18 4.71 5.25
40
TCG 55.1 52.6 50.1 47.4 44.7 41.9 39.1
SDT 83.9 93.4 103.0 113.0 123.0 132.0 142.0
KW 2.52 2.88 3.29 3.74 4.23 4.77 5.34
45
TCG 60.0 57.4 54.7 51.9 49.0 46.0 43.0
SDT 86.0 95.5 105.0 115.0 124.0 134.0 144.0
KW 2.55 2.92 3.33 3.79 4.29 4.84 5.43
50
TCG 65.2 62.4 59.6 56.6 53.5 50.3 47.1
SDT 88.3 97.7 107.0 117.0 126.0 136.0 146.0
KW 2.59 2.96 3.38 3.84 4.35 4.91 5.51
55
TCG 70.7 67.7 64.6 61.5 58.2 54.8 51.3
SDT 90.7 100.0 109.0 119.0 128.0 138.0 148.0
KW 2.64 3.01 3.43 3.90 4.42 4.98 5.60
594D060-E
30
TCG 55.1 52.7 50.1 47.4 44.8 42.2 39.5
SDT 80.2 89.9 99.7 109.0 119.0 129.0 139.0
KW 3.06 3.44 3.86 4.34 4.87 5.46 6.07
35
TCG 60.3 57.7 55.0 52.1 49.2 46.4 43.5
SDT 82.1 91.8 101.0 111.0 121.0 131.0 141.0
KW 3.10 3.49 3.92 4.40 4.93 5.53 6.17
40
TCG 65.7 63.0 60.1 57.1 54.0 50.9 47.8
SDT 84.1 93.7 103.0 113.0 123.0 133.0 143.0
KW 3.16 3.55 3.99 4.47 5.01 5.61 6.27
45
TCG 71.4 68.6 65.6 62.3 59.0 55.6 52.3
SDT 86.3 95.9 105.0 115.0 125.0 135.0 144.0
KW 3.21 3.62 4.06 4.55 5.09 5.69 6.36
50
TCG 77.4 74.5 71.3 67.8 64.3 60.6 57.0
SDT 88.6 98.1 108.0 117.0 127.0 136.0 146.0
KW 3.28 3.69 4.14 4.64 5.19 5.79 6.46
55
TCG 83.8 80.7 77.3 73.7 69.9 66.0 62.0
SDT 91.1 101.0 110.0 120.0 129.0 139.0 148.0
KW 3.35 3.77 4.23 4.74 5.29 5.90 6.58
