5
DISPLAY PANELS
SELECTED TEMPERATURE /
SELF-DIAGNOSTIC CODES indicator
DEFROST indicator
Illuminates when the coil is warming up to prevent
cold blow or when the unit goes into defrost mode.
OPERATION indicator
This indicator flashes once per second after power is
on and illuminates when the unit is in operation.
TIMER indicator
Illuminates during TIMER operation
A14356
Fig. 4 − Display Panel
Remote LCD Screen Indicators
MODE display
Displays the current
mode, including:
AUTO
COOL
DRY
HEAT
FAN
Transmission Indicator
Lights up when the remote sends a
signal to indoor unit
ON/OFF display
Appears when the unit is turned on,
and disappears when it is turned off
TIMER ON display
Displays when TIMER
ON is set
TIMER OFF display
Displays when TIMER
OFF is set
SLEEP display
Battery display
FRESH display
SILENT display
ECO display
Displays when
SLEEP function
is activated
FOLLOW ME
display
Indicates that
the FOLLOW ME
function is on
FAN SPEED display
Displays selected FAN SPEED:
HIGH, MED,
or LOW
This display is blank when
set to AUTO speed or DRY mode.
Temperature/Timer display
Displays the set temperature by default, or timer setting
when using TIMER ON/OFF functions
o
Temperature range: 62-86 F
Timer setting range: 0-24 hours
This display is blank when operating in FAN mode.
Displays when silence function
is activated
Not available for
this unit
Not available for
this unit
Low battery
detection
Fig. 5 − Unit Display
