7
REMOTE CONTROL FUNCTIONS
Pressing On/Off
When the air conditioner is not in operation, the remote control
displays the last set point and mode.
S Press ON/OFF to start the unit.
− The unit starts in the last operating mode and set
point. The ON/OFF indicator appears.
S Press ON/OFF to stop the unit.
− All the indicator lights on the unit go out, and the remote
control displays the set point and mode.
NOTE: If ON/OFF is pressed too soon after a stop, the
compressor will not start for 3 to 4 minutes due to the inherent
protection against frequent compressor cycling. The unit only
emits an audible beep when the signals are received correctly.
Selecting an Operating Mode
Use OPERATING MODE to select one of the available modes.
Fig. 9 − Display
Setting the Room Temperature Set Point
Press the increase temperature set point ▲ and decrease ▼ buttons
to raise or lower the temperature.
The unit confirms the signal receipt with a beep and the value of
the set temperature appears on the display and changes
accordingly. The temperature can be set between 62_F (17_C) and
86_F (30_C) in increments of 1_F or 1_C.
NOTE: In the COOLING mode, if the temperature selected is
higher than the room temperature, the unit will not start. The same
applies for the HEATING mode if the selected temperature is
lower than the room temperature.
Selecting the Fan Speed
AUTO
LOW
MED
HIGH
A14362
Fig. 10 − Fan Speeds
The fan speed can be selected by pressing FAN.
NOTE: When the unit is on, the fan runs continuously in cooling
or heating. When in heating, there might be situations where the
fan will slow down or shut off to prevent cold blow.
Selecting the Up−Down Louver Position
To optimize comfort, the Up−Down louver operates in a preset
range as shown in the figure below.
COOLING
HEATING
A08044
Fig. 11 − Louver Position
The up−down airflow louver can be adjusted by pressing DIRECT
on the remote control and can be set to be stationary or moving
continuously pressing SWING. The up−down louver position is
stored in the settings, however it is deactivated when the TURBO or
MANUAL settings are set, or when a power interruption takes place.
Air Direction
Press DIRECT repeatedly to choose one of the up−down louver
positions. Every time this button is pushed, the specific louver
swings by 6 degrees.
In the COOLING, DRY, and FAN ONLY modes, the louver
swings in the cooling range. In the HEATING mode, the louver
swings in the heating range.
NOTE: Always use the remote control to adjust the up−down
louver position, otherwise abnormal operation may occur. If the
up−down louver is manually adjusted out of its range, power the
unit off and then back on again.
Auto Swing
For automatic up−down louver swing, push SWING.
Selecting Right−Left Direction of the Louver
The right-left louvers can be adjusted manually to direct the airflow
to achieve optimal comfort in the space.
A07543
Fig. 12 − Louver
Timer Function
TIMER ON (to start the unit) and TIMER OFF (to stop the unit)
can be used separately or together.
Timer ON only
This function allows the unit to start automatically at the set time.
The TIMER ON function can be set while the unit is on or off.
UNIT ON
a. Press TIMER ON
to initiate the auto-on time
sequence. The set time is displayed in the remote control
display. Every time TIMER ON is pressed, the time
increases by 30 minutes, up to 10 h. It increases by 60
minutes, afterwards, until the time setting reaches 24 h.
b. When the TIMER ON is set, the TIMER light on unit
illuminates. The unit continues to run at the set time.
UNIT OFF
a. Set the timer described in the UNIT ON section.
b. The unit starts at the set time.
Adjust the TIMER ON settings to 0.0 to cancel this option.
