—14—
*Tested combination.
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Outdoor section/indoor section tested combination tested in accordance with DOE test procedures for heat pumps. Ratings for other combinations are
determined under DOE computer simulation procedures.
3. Ratings are based on:
Cooling Standard: 80°F dry bulb, 67°F wet bulb indoor entering air temperature and 95°F dry bulb outdoor entering air temperature.
High-Temp Heating Standard: 70°F dry bulb indoor entering air temperature and 47°F dry bulb, 43°F wet bulb outdoor entering air temperature.
Low-Temp Heating Standard: 70°F dry bulb indoor entering air temperature and 17°F dry bulb, 15°F wet bulb outdoor entering air temperature.
4. Cooling rating values reflect the use of the required
balanced-port, hard shutoff, Puron refrigerant compatible TXV in the indoor section.
5. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
6. Do not apply to capillary tube coils.
7. Coefficient of Performance (COP) can be calculated by using the Heat Pump Heating Performance tables. Normally the high temperature COP is calcu-
lated at 47°F, and the low temperature COP is calculated at 17°F. The formula for calculating the COP is as follows:
COP = TC
kW x 3413
EER — Energy Efficiency Ratio SEER — Seasonal Energy Efficiency Ratio
COP — Coefficient of Performance HSPF — Heating Seasonal Performance Factor
TC — Total Capacity (Btuh) kW — power input in kilowatts
CFM — Indoor airflow in cubic feet per minute
060-C
CK5PX060 1750 1050 59,000 28,600 14.00 10.15 55,000 26,000 3.30 3.58 32,800 11,400 2.42 1.80 8.00
COILS + 315(A,J)AV066135 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 56,000 27,600 13.50 9.70 53,500 25,000 3.04 3.36 31,600 11,000 2.30 1.72 7.80
CC5A/CD5AW060 1750 1050 57,500 28,200 14.00 9.95 54,000 25,600 3.22 3.50 32,400 11,200 2.38 1.80 8.10
CE3AA060 1750 1050 58,500 28,400 14.00 10.00 54,000 25,600 3.22 3.50 32,400 11,300 2.38 1.78 8.20
CK3BA060 1750 1050 57,500 28,400 14.00 9.95 55,000 26,000 3.28 3.56 32,800 11,400 2.40 1.78 7.90
CK5A/CK5BA060 1750 1050 58,000 28,400 14.00 10.00 55,000 26,000 3.30 3.58 32,800 11,400 2.40 1.78 7.90
CK5A/CK5BT060 1750 1050 58,000 28,400 14.00 10.00 55,000 26,000 3.30 3.58 32,800 11,400 2.40 1.78 7.90
CK5A/CK5BX060 1750 1050 59,000 28,600 14.50 10.10 55,000 26,000 3.28 3.60 33,000 11,400 2.42 1.80 8.00
CK5PA060 1750 1050 58,000 28,400 14.00 10.00 55,000 26,000 3.30 3.58 32,800 11,400 2.40 1.78 7.90
CK5PT060 1750 1050 58,000 28,400 14.00 10.00 55,000 26,000 3.30 3.58 32,800 11,400 2.40 1.78 7.90
CK5PX060 1750 1050 59,000 28,600 14.50 10.10 55,000 26,000 3.28 3.60 33,000 11,400 2.42 1.80 8.00
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 56,000 27,600 13.50 9.75 53,500 25,000 3.06 3.38 31,600 11,000 2.32 1.72 7.80
CC5A/CD5AW060 1750 1050 57,500 28,200 14.00 10.05 54,000 25,600 3.22 3.50 32,200 30,600 2.40 3.52 9.00
CE3AA060 1750 1050 58,500 28,200 14.00 10.10 54,000 25,600 3.22 3.52 32,400 11,200 2.40 1.78 8.20
CK3BA060 1750 1050 58,000 28,400 14.00 10.05 55,000 26,000 3.30 3.58 32,800 11,400 2.42 1.80 8.30
CK5A/CK5BA060 1750 1050 57,500 28,200 14.00 10.00 55,000 26,000 3.30 3.58 32,800 11,300 2.42 1.78 8.30
CK5A/CK5BT060 1750 1050 57,500 28,200 14.00 10.00 55,000 25,600 3.30 3.52 32,800 11,300 2.42 1.78 8.20
CK5A/CK5BX060 1750 1050 58,500 28,600 14.50 10.10 55,000 26,000 3.30 3.60 32,800 11,400 2.44 1.80 8.40
CK5PA060 1750 1050 57,500 28,200 14.00 10.00 55,000 26,000 3.30 3.58 32,800 11,300 2.42 1.78 8.30
CK5PT060 1750 1050 57,500 28,200 14.00 10.00 55,000 25,600 3.30 3.52 32,800 11,300 2.42 1.78 8.20
CK5PX060 1750 1050 58,500 28,600 14.50 10.10 55,000 26,000 3.30 3.60 32,800 11,400 2.44 1.80 8.40
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 55,000 27,200 13.00 9.05 53,000 25,000 2.86 3.24 33,200 11,200 2.22 1.66 7.60
CD5PX060 1750 1050 57,500 28,200 13.50 9.30 56,500 26,200 3.16 3.46 34,200 11,600 2.32 1.74 7.80
CE3AA060 1750 1050 57,000 28,000 13.50 9.30 55,500 25,400 3.00 3.38 33,800 11,400 2.30 1.70 7.60
CK3BA060 1750 1050 56,500 28,000 13.50 9.30 56,000 26,000 3.08 3.42 34,200 11,500 2.32 1.74 7.70
CK5A/CK5BA060 1750 1050 56,500 28,000 13.50 9.30 56,000 26,000 3.08 3.44 34,200 11,500 2.34 1.74 7.70
CK5A/CK5BT060 1750 1050 56,500 28,000 13.50 9.30 56,000 26,000 3.08 3.44 34,200 11,500 2.34 1.74 7.70
CK5A/CK5BX060 1750 1050 58,000 28,200 13.70 9.40 56,000 25,400 3.10 3.46 33,800 11,600 2.30 1.74 7.70
CK5PA060 1750 1050 56,500 28,000 13.50 9.30 56,000 26,000 3.08 3.44 34,200 11,500 2.34 1.74 7.70
CK5PT060 1750 1050 56,500 28,000 13.50 9.30 56,000 26,000 3.08 3.44 34,200 11,500 2.34 1.74 7.70
CK5PX060 1750 1050 58,000 28,200 13.50 9.40 56,000 25,400 3.10 3.46 33,800 11,600 2.30 1.74 7.70
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 55,000 27,200 13.00 9.15 52,500 25,000 2.88 3.26 32,800 11,200 2.24 1.66 7.60
CD5PX060 1750 1050 57,500 28,200 13.50 9.45 56,000 26,200 3.18 3.48 34,000 11,600 2.34 1.74 7.80
CE3AA060 1750 1050 57,000 28,000 13.50 9.45 55,000 25,600 3.02 3.38 33,600 11,400 2.32 1.72 7.60
CK3BA060 1750 1050 56,500 28,000 13.50 9.40 56,000 26,000 3.10 3.44 34,000 11,500 2.36 1.74 7.80
CK5A/CK5BA060 1750 1050 56,500 28,000 13.70 9.40 56,000 26,000 3.10 3.44 34,000 11,500 2.36 1.74 7.80
CK5A/CK5BT060 1750 1050 56,500 28,000 13.50 9.40 56,000 26,000 3.10 3.44 34,000 11,500 2.36 1.74 7.80
CK5A/CK5BX060 1750 1050 58,000 28,400 13.50 9.55 56,000 26,000 3.12 3.46 33,600 11,600 2.32 1.74 7.70
CK5PA060 1750 1050 56,500 28,000 13.50 9.40 56,000 26,000 3.10 3.44 33,800 11,500 2.36 1.74 7.80
CK5PT060 1750 1050 56,500 28,000 13.50 9.40 56,000 26,000 3.10 3.44 34,000 11,500 2.36 1.74 7.80
CK5PX060 1750 1050 58,000 28,400 13.50 9.55 56,000 26,000 3.12 3.46 33,600 11,600 2.32 1.74 7.70
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 1750 1050 55,000 27,200 13.00 9.25 52,500 25,000 2.90 3.26 32,800 11,100 2.26 1.66 7.60
CD5PX060 1750 1050 57,500 28,200 13.50 9.55 56,000 26,000 3.20 3.50 33,800 11,200 2.36 1.74 7.80
CE3AA060 1750 1050 57,500 28,000 13.50 9.55 55,000 25,200 3.02 3.40 33,400 11,300 2.32 1.72 7.90
CK3BA060 1750 1050 57,000 28,000 13.50 9.50 56,000 25,400 3.12 3.46 33,800 11,300 2.36 1.72 7.80
CK5A/CK5BA060 1750 1050 57,000 28,000 13.50 9.50 55,500 25,400 3.12 3.48 33,800 11,300 2.36 1.74 7.80
CK5A/CK5BT060 1750 1050 57,000 28,000 13.50 9.50 55,500 25,400 3.12 3.48 33,800 11,300 2.36 1.74 7.80
CK5A/CK5BX060 1750 1050 58,000 28,200 13.50 9.65 55,500 26,000 3.12 3.46 33,400 11,500 2.34 1.74 7.80
CK5PA060 1750 1050 57,000 28,000 13.50 9.50 56,000 25,400 3.12 3.48 33,800 11,300 2.36 1.74 7.80
CK5PT060 1750 1050 57,000 28,000 13.50 9.50 56,000 25,400 3.12 3.48 33,800 11,300 2.36 1.74 7.80
CK5PX060 1750 1050 58,000 28,200 13.50 9.60 55,500 26,000 3.12 3.46 33,400 11,500 2.34 1.74 7.80
UNIT
SIZE
SERIES
INDOOR
UNIT
Heating
HSPF
Cooling
High-Temp Low-Temp
CFM TC
SEER EER
TC Cop TC Cop
High Low
High Low
High Low High Low High Low High Low
COMBINATION RATINGS Continued
